Specifications for 500 Plates. If any specification is not mentioned here, please use the contact button for quick quote.
| Item | Abrasion Resistant Plate |
| Material | 500 |
| Thickness | 4-80mm |
| Width | 500-3000mm |
| Length | 1000-12000mm |
| Heat Treatment | N, Q+T |
| Surface Paint | EP, PE, HDP, SMP, PVDF |
| Plate | thickness mm | 04/13/13 | (13)-32 | (32)-40 | (40)-80 |
| C | max % | 0.27 | 0.29 | 0.29 | 0.3 |
| Si | max % | 0.7 | 0.7 | 0.7 | 0.7 |
| Mn | max % | 1.6 | 1.6 | 1.6 | 1.6 |
| P | max % | 0.025 | 0.025 | 0.025 | 0.025 |
| S | max % | 0.01 | 0.01 | 0.01 | 0.01 |
| Cr | max % | 1 | 1 | 1 | 1.5 |
| Ni | max % | 0.25 | 0.5 | 1 | 1.5 |
| Mo | max % | 0.25 | 0.3 | 0.6 | 0.6 |
| B | max % | 0.004 | 0.004 | 0.004 | 0.004 |
| CEV | typv | 0.49 | 0.62 | 0.64 | 0.74 |
| CET | typv | 0.34 | 0.41 | 0.43 |
| Hardness, HB | 470-530 |
| Yield Strength, ksi | 190,000 |
| Tensile Strength, ksi | 225,000 |
| Impact Properties @ -40° F, min | 22 ft. lbs. |
Contact us or click on the below button to request a latest 500 Plates price list. dedicated to providing the world-class 500 Plates that cater to all your demands at very competitive rates.
Material Testing:
Documentation & Packaging:
