China ASTM A204 Alloy Steel Plate 100mm Thickness 16Mo3 Molybdenum for sale

ASTM A204 Alloy Steel Plate 100mm Thickness 16Mo3 Molybdenum

Price Negotiable
Price: 1.2 USD/KG
MOQ: 10KGS
Delivery Time: 7 Days
Brand: MITTEL TISCO BAO STEEL
Product Description

16Mo3 Sheets & Plates Specifications

Specifications for 16Mo3 Sheets & Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Specifications ASTM A204 / ASME SA204
Standard AISI, ASTM, BS, DIN, GB, JIS
Thickness 4.0mm – 100mm
Specialize Shim Sheet, Perforated Sheet, B. Q. Profile.
Length 1000-12000 mm
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange)
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Grade ASTM A204 16MO3

Types of 16Mo3 Sheets & Plates



  • ASTM 16Mo3 Steel Polished Sheets
  • WERKSTOFF NR. 1.5415 Polished Sheets
  • ASTM 16Mo3 Steel Hot Rolled Sheets
  • ASTM 16Mo3 Steel Cold Rolled Sheets
  • ASTM 16Mo3 Steel Sheets
  • ASTM 16Mo3 Steel Shim Sheets
  • ASTM 16Mo3 Steel Perforated Sheets
  • ASTM 16Mo3 Steel Class 1 Sheets
  • ASTM 16Mo3 Steel Plates





  • WERKSTOFF NR. 1.5415 Hot Rolled Plates
  • ASTM 16Mo3 Steel Checkered Plates
  • ASTM 16Mo3 Steel Cold Rolled Plates
  • WERKSTOFF NR. 1.5415 Cold Rolled Plates
  • ASTM 16Mo3 Steel Polished Plates
  • WERKSTOFF NR. 1.5415 Polished Plates
  • ASTM 16Mo3 Hot Rolled Plates
  • ASTM 16Mo3 Steel Cold Rolled Plates
  • ASTM 16Mo3 Steel Class 1 Plates





16Mo3 Sheets & Plates Chemical Composition

Grade min max
C 0.12 0.2
Cu – 0.30
N – 0.012
Mn 0.40 0.90
Mo 0.25 0.35
P – 0.025
Si – 0.35
S – 0.01
Cr – 0.30
Ni – 0.30



Mechanical Properties of 16Mo3 Sheets & Plates

Properties 16Mo3
Tensile Strength (Mpa) 440-590
Yield Strength (Mpa) 220-275
Elongation in 100-150 mm(%) 19
Elongation in 16 mm(%) 24
Max Thickness (mm) 250
Shear Modulus 79.3 GPa



16Mo3 Sheets & Plates – Equivalent Grades

STANDARD 16Mo3
WERKSTOFF NR. 1.5415
UNS –
JIS JIS G3115
EN EN10028
BS 1503-243B
GOST –
