Stainless Steel CF18 B Track Runner Bearings for Medical Equipment
Stainless Steel CF18 B Cylindrical Roller Bearings for Medical Equipment
Bearing Specification :
| FSK BEARING Model Number | CF18 B |
| Part Name | Truck Roller Bearing |
| Brand | FSK / TR / ASAHI / FYH / NSK / NTN / OEM |
| Cage | Steel, Brass, Nylon |
| Bearing Material | Chrome Steel / Stainless Steel |
| Precision Grade | ABEC-1 to ABEC-9 ; P0 to P6 |
| Dimensions(mm)(d*D*b) | 18mm × 40mm × 20mm |
| Weight / Mass ( KG ) | 0.25kg |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
Track Roller Bearing List:
| Model No. | Main dimensions | With cage | Full-roller type | Mass | |||||||
| Outer diameter D |
Threaded G |
Outer ring width C |
B | Overall length B1 |
Dynamic rating C |
Static rating C0 |
Dynamic rating C |
Static rating C0 |
With cage | Full-roller type | |
| mm | mm | mm | mm | mm | kN | kN | kN | kN | g | g | |
| CF 3-A | 10 | M3x0.5 | 7 | 8 | 17 | 1.47 | 1.18 | - | - | 4.5 | - |
| CF 4-A | 12 | M4x0.7 | 8 | 9 | 20 | 2.06 | 2.05 | - | - | 7.5 | - |
| CF 5-A | 13 | M5x0.8 | 9 | 10 | 23 | 3.14 | 2.77 | - | - | 10.5 | - |
| CF 6-A | 16 | M6x1 | 11 | 12 | 28 | 3.59 | 3.58 | 6.94 | 8.5 | 18.5 | 19 |
| CF 8-A | 19 | M8x1.25 | 11 | 12 | 32 | 4.17 | 4.65 | 8.13 | 11.2 | 28.5 | 29 |
| CF 10-A | 22 | M10x1.25 | 12 | 13 | 36 | 5.33 | 6.78 | 9.42 | 14.3 | 45 | 46 |
| CF 10-1-A | 26 | M10x1.25 | 12 | 13 | 36 | 5.33 | 6.78 | 9.42 | 14.3 | 60 | 61 |
| CF 12-A | 30 | M12x1.5 | 14 | 15 | 40 | 7.87 | 9.79 | 13.4 | 19.8 | 95 | 97 |
| CF 12-1-A | 32 | M12x1.5 | 14 | 15 | 40 | 7.87 | 9.79 | 13.4 | 19.8 | 105 | 107 |
| CF 16-A | 35 | M16x1.5 | 18 | 19.5 | 52 | 12 | 18.3 | 20.6 | 37.6 | 170 | 173 |
| CF 18-A | 40 | M18x1.5 | 20 | 21.5 | 58 | 14.7 | 25.2 | 25.2 | 51.3 | 250 | 255 |
| CF 20-A | 52 | M20x1.5 | 24 | 25.5 | 66 | 20.7 | 34.8 | 33.2 | 64.8 | 460 | 465 |
| CF 20-1-A | 47 | M20x1.5 | 24 | 25.5 | 66 | 20.7 | 34.8 | 33.2 | 64.8 | 385 | 390 |
| CF 24-A | 62 | M24x1.5 | 29 | 30.5 | 80 | 30.6 | 53.2 | 46.7 | 92.9 | 815 | 820 |
| CF 24-1-A | 72 | M24x1.5 | 29 | 30.5 | 80 | 30.6 | 53.2 | 46.7 | 92.9 | 1140 | 1140 |
| CF 30-A | 80 | M30x1.5 | 35 | 37 | 100 | 45.4 | 87.6 | 67.9 | 145 | 1870 | 1870 |
| CF 30-1-A | 85 | M30x1.5 | 35 | 37 | 100 | 45.4 | 87.6 | 67.9 | 145 | 2030 | 2030 |
| CF 30-2-A | 90 | M30x1.5 | 35 | 37 | 100 | 45.4 | 87.6 | 67.9 | 145 | 2220 | 2220 |
Bearings Detailed Pictures :
Features:
CF Camrol series steel stud-type cam follower bearing with lip seals and a hexagonal hole supports high static and dynamic loads in cam- and track-type applications. This precision cam follower has a thick-walled outer ring that helps minimize deformation under heavy radial and shock loads. It has a threaded stud-type design for through-hole or threaded mounting, and a hexagonal hole on the flange end that provides greater holding power during mounting than a screwdriver slot.
