NA495 Miniature Caged Needle Bearings 5mm × 13mm × 10mm , Metric
Price:
0.1-20USD
MOQ:
1 pcs-5pcs
Delivery Time:
3-7Days After Deposit
Brand:
IKO / INA / FAG / NSK / NTN / FSK / OEM
Product Description
NA495 Miniature Caged Needle Bearings 5mm × 13mm × 10mm , Metric
NA Series Needle Roller Bearings Drawing :
Bearing Specification :
| Model Number | NA495 |
| Part Name | Needle Roller Bearing |
| Brand | IKO / INA / FAG / NSK / NTN / FSK / OEM |
| Precision Rating | P6 / P4 / P5 |
| Material | Chrome Steel / Stainless Steel |
| Inner Ring | with Inner Ring |
| Row | Double Row |
| Dimensions(mm)(d*D*b) | 5mm × 13mm × 10mm |
| Weight / Mass ( KG ) | 0.007kg |
| HS Code | 8482800000 |
| Original Country Show | CHINA |
Needle Roller Bearings Description :
1. Drawn Cup Needle Bearing
| HK Seires | ||
| HK0408TN | HK1212 | BK1210 |
| HK0509 | HK1312 | BK1212 |
| HK0608 | HK1412 | HK08X14X10 |
| HK0609 | BK1312 | HK08X14X12 |
| HK0708 | BK0408TN | HK10X16X10 |
| HK0709 | BK0509 | HK10X16X12 |
| HK0808 | BK0609 | HK12X18X12 |
| HK0810 | BK0709 | HK10X16X15 |
| HK0910 | BK0808 | HK12X17X12 |
| HK0912 | BK0810 | HK12X17X15 |
| HK1010 | BK0910 | HK12X17X18 |
| HK1012 | BK0912 | BK12X18X12 |
| HK1015 | BK1010 | HK12X19X12 |
| HK1210 | BK1012 | |
2. Needle Bearing with Inner Ring
| NA Series | ||
| NA4822A | NA4844A/YA4 | NA4903AS2 |
| NA4824 | NA4852A | NA4904A |
| NA4824A | NA4856A | NA4904A/YA2 |
| NA4826A | NA4900A | NA4904 |
| NA4826 | NA4900A/YA | NA49/22 |
| NA4828A | NA4900 | NA4905A |
| NA4828 | NA4901A | NA4505 |
| NA4832A | NA4901 | NA49/28 |
| KA4832A | NA4902 | NA4906A |
| NA4836A | NA4903A | NA4906 |
| NA4844A | NA4903 | NA49/32 |
3. Needle Bearing without Inner Ring
| RNA Series | ||
| RNA49/8A | RNA4904A | RNA4908A |
| RNA49/9A | RNA4905A | RNA4909A |
| RNA4900A | RNA4906A | RNA4909AF1 |
| RNA4901A | RNA4907A | RNA4910A |
| RNA4902A | RNA4907A/AS4 | RNA4910A/YB2 |
| RNA4902AF | RNA4907AF1 | RNA4911A |
| RNA4903A | ||
4. Radial Needle Roller and Cage Assemblie
| K Series | ||
| K15x19x8 | K7x10x8TN | K14x18x10/YA5 |
| K16x20x8H | K7x10x8TNA | K15x19x10 |
| K18x22x8 | K8x11x8 | K16x20x10 |
| K5x8x8TN | K8x11x8TN | K17x21x10 |
| K6x9x8 | K10x13x8 | K17x21x10TV |
| K6x9x8/SO | K14x18x10 | K18x22x10 |
| K7x10x8 | ||
Needle Roller Bearings List :
|
Shaft Diameter |
Bearing Designation | Mass | BoundaryDimensions | BasicLoad Rating |
Limiting Speed |
|||||
| CurrentCode | OriginalCode | Approx | Dynamic | Static | ||||||
| mm | g | mm | N | rpm | ||||||
| 5 | NA495 | 7 | 5 | 13 | 10 | 2670 | 2350 | 34000 | ||
| NA495TN | 7 | 5 | 13 | 10 | 2670 | 2350 | 34000 | |||
| 6 | NA496 | 9 | 6 | 15 | 10 | 3150 | 3000 | 32000 | ||
| 7 | NA497 | 12 | 7 | 17 | 10 | 3600 | 3650 | 30000 | ||
| 8 | NKI8/16 | 8 | 14 | 25 | 16 | 12400 | 11300 | 21500 | ||
| NA498 | 16 | 8 | 19 | 11 | 4300 | 3950 | 28000 | |||
| 9 | NKI9/12 | 16.6 | 9 | 12 | 19 | 12 | 6200 | 7000 | 21700 | |
| NA499 | 17 | 9 | 20 | 11 | 4850 | 4900 | 26000 | |||
| NKI9/16 | 21.9 | 9 | 19 | 16 | ||||||
| 10 | NKI10/16 | 27.3 | 10 | 14 | 22 | 16 | 9800 | 10500 | 19650 | |
| NA4900 | 4524900 | 21 | 10 | 14 | 22 | 13 | 8000 | 9000 | 23700 | |
| NA6900 | 6534900 | 38.4 | 10 | 14 | 22 | 22 | 9000 | 11000 | 23700 | |
| 12 | NA4901 | 4524901 | 25.1 | 12 | 16 | 24 | 13 | 9000 | 10800 | 20000 |
| NKI12/20 | 39 | 12 | 16 | 24 | 20 | 14000 | 18400 | 21000 | ||
| NA6901 | 6534901 | 44.5 | 12 | 16 | 24 | 22 | 6000 | 21600 | 20000 | |
| NKIS12 | 58 | 12 | 18 | 30 | 16 | 16000 | 17000 | 20000 | ||
| NA12X32X15V | 12 | 32 | 15 | |||||||
| 15 | NKI15/16 | 38 | 15 | 19 | 27 | 16 | 8800 | 12800 | 19100 | |
| NKI15/20 | 45.7 | 15 | 19 | 27 | 20 | 12300 | 19000 | 19100 | ||
| NA4902 | 4924902 | 32 | 15 | 20 | 28 | 13 | 6400 | 9000 | 18000 | |
| NA6902 | 6534902 | 61.6 | 15 | 20 | 28 | 23 | 13100 | 20900 | 18000 | |
| NKIS15 | 90 | 15 | 22 | 35 | 20 | 23500 | 24000 | 17000 | ||
| NA5902 | 52 | 15 | 20 | 28 | 18 | |||||
| NAI53212 | 15 | 32 | 12 | |||||||
| 74802 | 74802 | 15 | 36 | 25.4 | ||||||
| 16 | NKIS16 | 16 | 28 | 16 | 13000 | 17400 | 22000 | |||
| NA16X36X24 | 16 | 36 | 24 | |||||||
| 17 | NKI17/16 | 41.1 | 17 | 21 | 29 | 16 | 13000 | 18200 | 20000 | |
| NA4903 | 4544903 | 32.8 | 17 | 22 | 30 | 13 | 7000 | 10000 | 17000 | |
| NA6903 | 6534903 | 68.2 | 17 | 22 | 30 | 23 | 14400 | 24900 | 17000 | |
| NA5903 | 56 | 17 | 22 | 30 | 18 | 15200 | 21700 | 18000 | ||
| NA17 | 17 | 37 | 20 | |||||||
Details about FSK Needle Roller Bearings:
| Needle roller bearings | NK,NKS,RNA49,RNA69,RNAO,NKI,NKIS,NA49, |
| NA69,NAV,RNAV,RNA49..RS,RNA49..2RS | |
| Radial needle roller and | K,KZK,KNL,K..ZW,KBK |
| cage assemblies | |
| Drawn cup needle roller bearing | HK,BK,HK..2RS,MFY,SCE,BCE,BK..RS,F,HK..RS,MF,FY |
| Inner ring | IR,LR |
| Yoke type track rollers | RSTO,RNA22..2RSX,NATV,STO,NA22..2RS, |
| NATV..PP,STO..X,NA22..2RSX,NUTR,RNA22..2RS, | |
| NATR,NUTR.X | |
| Curve rollers | KR,KRV,KRVE..PP,KR..PP,KRV..PP,NUKR, |
| KRE..PP,KRVE,NUKRE | |
| Combined radial thrust bearings | NKIA,NKX,NKX..Z,NKIB,NKXR,NKXR..Z,NX,NX..Z |
| One way clutch | HF,HFL |
| Axial bearings | AXK,AXW |
Bearings Detailed Pictures :
NA495 Miniature Caged Needle Bearings 5mm × 13mm × 10mm , Metric , Get Cheap Price from China Bearing Factory Now !
