Stainless Steel Thin Section 6802ZZ IJK Ball Bearing Radial Load Metal Shield
Price:
Low Price
MOQ:
1 pcs
Delivery Time:
7Days After Order Confirmed
Brand:
IJK / NSK / FAG / NTN / KOYO / FSK / OEM
Product Description
Thin Section 6802ZZ IJK Ball Bearing Radial Load Metal Shield
6802ZZ Bearing Specification
Bearing No. : 6802ZZ
Seal Type: metal shield or open
Mass: 0.007KG
Dynamic load rating Cr: 1.59KN
Static load rating Cor: 0.98KN
dimensions: 15*24*5mm
Inner Diameter: 15mm
Outer Diameter: 24mm
Width: 5mm
Bearings Detailed Pictures
68 Series Deep Groove Ball Bearings List
| Bearing No | ID(mm) | OD(mm) | Width B(mm) | Load Rating | Weight(kg) | |
| Dynamic | Static | |||||
| 685 | 5 | 11 | 5 | 0.6 | 0.28 | 0.0016 |
| 686 | 6 | 13 | 5 | 0.83 | 0.39 | 0.0025 |
| 687 | 7 | 14 | 5 | 0.9 | 0.44 | 0.0028 |
| 688 | 8 | 16 | 5 | 1.23 | 0.63 | 0.004 |
| 689 | 9 | 17 | 5 | 1.23 | 0.63 | 0.0043 |
| 6800 | 10 | 19 | 5 | 1.32 | 0.7 | 0.005 |
| 6801 | 12 | 21 | 5 | 1.47 | 0.84 | 0.006 |
| 6802 | 15 | 24 | 5 | 1.59 | 0.98 | 0.007 |
| 6803 | 17 | 26 | 5 | 1.7 | 1.05 | 0.008 |
| 6804 | 20 | 32 | 7 | 2.68 | 1.74 | 0.018 |
| 6805 | 25 | 37 | 7 | 2.84 | 1.96 | 0.022 |
| 6806 | 30 | 42 | 7 | 3.087 | 2.352 | 0.026 |
| 6807 | 35 | 47 | 7 | 4.9 | 4 | 0.03 |
| 6808 | 40 | 52 | 7 | 5.1 | 4.4 | 0.033 |
| 6809 | 45 | 58 | 7 | 6.2 | 5.4 | 0.04 |
| 6810 | 50 | 65 | 7 | 6.6 | 6.1 | 0.052 |
Thin Section 6802ZZ IJK Ball Bearing Radial Load Metal Shield , Get Cheap Price from China Ball Bearing Factory Now !
