Screw Type PWKRE 90.2RS Needle Roller Bearings Eccentric Track Roller Bearing
Screw Type PWKRE 90.2RS Eccentric Track Roller Bearing Cam Followers
PWKRE 90.2RS Bearings Specification :
|
Model Number |
PWKRE 90.2RS |
|
Part Name |
Track Roller Bearing |
|
Brand |
INA / IKO / FSK / OEM Brand |
| Material | Gcr15 |
|
Dimensions(mm)(d*D*b) |
30mm × 90mm × 100mm |
|
Weight / Mass ( KG ) |
2.02kg |
|
HS Code |
8482800000 |
|
Original Country Show |
CHINA |
PWKRE 90.2RS Bearings Detailed Pictures :
PWKR Series Bearing Catalog
| Outside | Mass | Designation | Mass | Dimensions | ||||||
| Designation | D | d | C | r | B | B1 | ||||
| Diameter | g | With | g | |||||||
| Eccentric | ||||||||||
| Collar | min. | |||||||||
| 35 | PWKR35.2RS | 164 | -- | -- | 35 | 16 | 18 | 0.6 | 52 | 32.5 |
| -- | - | PWKRE35.2RS | 177 | 35 | 16 | 18 | 0.6 | 52 | 29.5 | |
| 40 | PWKR40.2RS | 242 | -- | -- | 40 | 18 | 20 | 1 | 58 | 36.5 |
| -- | - | PWKRE40.2RS | 258 | 40 | 18 | 20 | 1 | 58 | 33.5 | |
| 47 | PWKR47.2RS | 380 | PWKRE47.2RS | 400 | 47 | 20 | 24 | 1 | 66 | 40.5 |
| 52 | PWKR52.2RS | 450 | PWKRE52.2RS | 470 | 52 | 20 | 24 | 1 | 66 | 40.5 |
| 62 | PWKR62.2RS | 795 | PWKRE62.2RS | 824 | 62 | 24 | 28 | 1 | 80 | 49.5 |
| 72 | PWKR72.2RS | 1020 | PWKRE72.2RS | 1050 | 72 | 24 | 28 | 1.1 | 80 | 49.5 |
| 80 | PWKR80.2RS | 1600 | PWKRE80.2RS | 1670 | 80 | 30 | 35 | 1.1 | 100 | 63 |
| 90 | PWKR90.2RS | 1960 | PWKRE90.2RS | 2020 | 90 | 30 | 35 | 1.1 | 100 | 63 |
The Other Bearings We Do
| Ball Bearing | Deep Groove Ball Bearing | 60 **,618 ** (1008), 619**(1009),62 **, 63 **, 64 **, |
| 160 **(70001 ) | ||
| Thrust Ball Bearing | 511 ** (81) ,512 **(82) ,513 (83) ,514 ** (84) series and Angular Contact Thrust all Bearings like: 5617 ** (1687) ,5691 ** (91681), 5692 ** (91682) series | |
| Angular Contact Ball bearing | SN718 **(11068 ) ,70 ** 72 **,73 **, and B (66), C (36), AC (46) series ; otherwise include QJ and QJF series | |
| Roller Bearing | Spherical Roller bearing | 239**, 230**,240**, 231**, 241**, 222**, 232**, 223**, 233**, 213**, 238**, 248**, 249**and special series include 26** i.e 2638 (3738), 2644 (3844) and so on |
| Taper Roller Bearing | 329**(20079),210**(71), 320**(20071),302**(72), 322**(75), 303**(73), 313**(273),323**(76), 3519**(10979), 3529**(20979),3510**(971), 3520**(20971),3511**(10977), 3521**(20977), 3522**(975), 319**(10076),3819**(10779),3829**(20779), 3810**(777,771), 3820**(20771), 3811**(10777,777) for example: 77752, 77788, 77779 and also include Inch series bearings suchas 938/932 single and double row i.e M255410CD etc. | |
| Thrust Roller Bearing | 292**(90392), 293**(90393),294**(90394),994**(90194), and 9069 series. | |
| Cylindrical Roller Bearing | NU10**, NU2**,NU22**, NU3**,NU23**, NU4**, N, NJ ,NUP series as well as NB, NN, NNU series of big bearings, and we also have Split Bearings 412740, 422740 used in cement industry.And FC, FCD series used in Steel Industry. |
