Eccentric RN205M Cylindrical Roller Bearing Brass Cage for Reduction Box
Eccentric RN205M Cylindrical Roller Bearing Bearing Brass Cage for Reduction Box
RN205M Bearings Specification :
|
Model Number |
RN205M |
|
Part Name |
Eccentric Bearing |
|
Brand |
NTN / KOYO / FSK / OEM Brand |
| Material | Gcr15 |
|
Dimensions(mm)(d*D*b) |
25mm × 45mm × 15mm |
|
Weight / Mass ( KG ) |
0.1kg |
|
HS Code |
8482800000 |
|
Original Country Show |
CHINA |
RN Series Drawing and Specification
| Bearing No. | Specification ㎜ | China Old Model | ||||||
| EW | EW Tolerence | d | B | rsmin | D2max | a | ||
| RN204 | 40 | 0-0.010 | 20 | 14 | 1 | 37.3 | 3.75 | 502204 |
| RN205 | 45 | 0-0.015 | 25 | 15 | 1 | 42.3 | 4.25 | 502205 |
| RN206 | 53.5 | 30 | 16 | 1 | 50.5 | 4.25 | 502206 | |
| RN207 | 61.8 | 35 | 17 | 1.1 | 59 | 4 | 502207 | |
| RN208 | 70 | 40 | 18 | 1.1 | 66.2 | 4 | 502208 | |
| RN209 | 75 | 45 | 19 | 1.1 | 71.2 | 4.5 | 502209 | |
| RN210 | 80.4 | 50 | 20 | 1.1 | 77 | 5 | 502210 | |
| RN211 | 88.5 | 0-0.020 | 55 | 21 | 1.5 | 85 | 5 | 502211 |
| RN212 | 97.5 | 60 | 22 | 1.5 | 93.2 | 5 | 502212 | |
| RN213 | 105.6 | 65 | 23 | 1.5 | 101 | 5 | 502213 | |
| RN214 | 110.5 | 70 | 24 | 1.5 | 105.8 | 5.5 | 502214 | |
| RN215 | 116.5 | 75 | 25 | 2 | 111.4 | 5.5 | 502215 | |
| RN216 | 125.3 | 80 | 26 | 2 | 119.8 | 5.5 | 502216 | |
| RN217 | 133.8 | 85 | 28 | 2 | 129 | 6 | 502217 | |
| RN218 | 143 | 90 | 30 | 2.1 | 136.4 | 6 | 502218 | |
| RN219 | 151.5 | 95 | 32 | 2.1 | 145.5 | 6.5 | 502219 | |
| RN220 | 160 | 100 | 34 | 2.1 | 152.8 | 7 | 502220 | |
| RN221 | 168.8 | 105 | 36 | 2.1 | 161.2 | 7.5 | 502221 | |
| RN222 | 178.5 | 110 | 38 | 2.1 | 170.2 | 7.5 | 502222 | |
| RN224 | 191.5 | 120 | 40 | 2.1 | 183.5 | 8 | 502224 | |
| RN226 | 204 | 0-0.025 | 130 | 40 | 3 | 195 | 8 | 502226 |
| RN228 | 221 | 140 | 42 | 3 | 211.5 | 8 | 502228 | |
| RN230 | 238 | 150 | 45 | 3 | 228 | 8.5 | 502230 | |
| RN232 | 255 | 160 | 48 | 3 | 245 | 9 | 502232 | |
| RN234 | 272 | 170 | 52 | 4 | 262 | 10 | 502234 | |
| RN236 | 282 | 180 | 52 | 4 | 270 | 10 | 502236 | |
| RN238 | 299 | 190 | 55 | 4 | 286.5 | 10.5 | 502238 | |
| RN240 | 316 | 200 | 58 | 4 | 302.5 | 11.5 | 502240 | |
| RN204E | 41.5 | 0-0.010 | 20 | 14 | 1 | 37.3 | 2.5 | 502204E |
| RN205E | 46.5 | 0-0.015 | 25 | 15 | 1 | 42.3 | 3 | 502205E |
| RN206E | 55.5 | 30 | 16 | 1 | 50.5 | 3 | 502206E | |
| RN207E | 64 | 35 | 17 | 1.1 | 59 | 3 | 502207E | |
| RN208E | 71.5 | 40 | 18 | 1.1 | 66.2 | 3.5 | 502208E | |
| RN209E | 76.5 | 45 | 19 | 1.1 | 71.2 | 3.5 | 502209E | |
| RN210E | 81.5 | 50 | 20 | 1.1 | 77 | 4 | 502210E | |
| RN211E | 90 | 0-0.020 | 55 | 21 | 1.5 | 85 | 3.5 | 502211E |
| RN212E | 100 | 60 | 22 | 1.5 | 93.2 | 4 | 502212E | |
| RN213E | 108.5 | 65 | 23 | 1.5 | 101 | 4 | 502213E | |
| RN214E | 113.5 | 70 | 24 | 1.5 | 105.8 | 4 | 502214E | |
| RN215E | 118.5 | 75 | 25 | 2 | 111.4 | 4 | 502215E | |
| RN216E | 127.3 | 80 | 26 | 2 | 119.8 | 4.5 | 502216E | |
| RN217E | 136.5 | 85 | 28 | 2 | 129 | 4.5 | 502217E | |
| RN218E | 145 | 90 | 30 | 2.1 | 136.4 | 5 | 502218E | |
| RN219E | 154.5 | 95 | 32 | 2.1 | 145.5 | 5 | 502219E | |
| RN220E | 163 | 100 | 34 | 2.1 | 152.8 | 5 | 502220E | |
| RN221E | - | 105 | 36 | 2.1 | 161.2 | - | 502221E | |
| RN222E | 180.5 | 110 | 38 | 2.1 | 170.2 | 6 | 502222E | |
| RN224E | 195.5 | 120 | 40 | 2.1 | 183.5 | 6 | 502224E | |
Detailed Bearing Pictures:
Eccentric RN205M Cylindrical Roller Bearing Bearing Brass Cage for Reduction Box , Get Cheap Price from China Bearing Factory Now !
