Inched R24ZZ Miniature Ball Bearing Single Row Chrome Steel / RHP
Inched R24ZZ Miniature Ball Bearing Single Row Chrome Steel / RHP
R24ZZ Bearings Specification :
|
Model Number |
R24ZZ |
|
Part Name |
Deep Groove Ball Bearing |
|
Brand |
FAG / INA / NSK / KOYO / NACHI / NTN / FSK / OEM |
| Material | Gcr15 |
|
Dimensions(mm)(d*D*b) |
38.1mm × 66.675mm × 11.112mm |
|
Weight / Mass ( KG ) |
0.141kg |
|
HS Code |
8482109000 |
|
Original Country Show |
GERMANY ( FAG ) |
Part List of Our Miniature Bearings
| Bearing No. | Specification | Load Ratings | |||||||
| Open | ZZ | 2RS | d | D | width | r | Dynamic | Static | |
| Open | ZZ,2RS | ||||||||
| R8 | R8ZZ | R8-2RS | 12.7 | 28.575 | 6.35 | 7.938 | 0.3 | 5.1 | 2.38 |
| R10 | R10ZZ | R10-2RS | 15.875 | 34.925 | 7.14 | 8.73 | 0.3 | 6 | 3.25 |
| R12 | R12ZZ | R12-2RS | 19.05 | 41.275 | 7.938 | 11.112 | 0.6 | 9.38 | 5.02 |
| R14 | R14ZZ | R14-2RS | 22.225 | 47.625 | 9.525 | 12.7 | 0.6 | 10 | 5.85 |
| R16 | R16ZZ | R16-2RS | 25.4 | 50.8 | 9.525 | 12.7 | 0.6 | 10 | 5.85 |
| R18 | R18ZZ | R18-2RS | 28.575 | 53.975 | 9.525 | 12.7 | 1 | 13.2 | 8.3 |
| R20 | R20ZZ | R20-2RS | 31.75 | 57.15 | 9.525 | 12.7 | 1 | 13.2 | 8.3 |
| R22 | R22ZZ | R22-2RS | 34.925 | 63.5 | 11.112 | 14.288 | 1 | 16.2 | 10.5 |
| R24 | R24ZZ | R24-2RS | 38.1 | 66.675 | 11.112 | 14.288 | 1 | 17.03 | 11.7 |
| Bearing No. | Specification | Load Ratings | ||||||
| Open | ZZ | 2RS | d | D | B | r | Dynamic | Static |
| RLS4 | RLS4ZZ | RLS4-2RS | 12.7 | 33.338 | 9.525 | 0.6 | 6.82 | 3.05 |
| RLS5 | RLS5ZZ | RLS5-2RS | 15.875 | 39.688 | 11.112 | 0.6 | 7.65 | 3.72 |
| RLS6 | RLS6ZZ | RLS6-2RS | 19.05 | 47.625 | 14.288 | 1 | 12.8 | 6.65 |
| RLS7 | RLS7ZZ | RLS7-2RS | 22.225 | 50.8 | 14.288 | 1 | 12.8 | 6.65 |
| RLS8 | RLS8ZZ | RLS8-2RS | 25.4 | 57.15 | 15.875 | 1 | 14 | 7.88 |
| RLS9 | RLS9ZZ | RLS9-2RS | 28.575 | 63.5 | 15.875 | 1 | 19.5 | 10 |
| RLS10 | RLS10ZZ | RLS10-2RS | 31.75 | 69.85 | 17.46 | 1.1 | 22.5 | 11.8 |
| RLS11 | RLS11ZZ | RLS11-2RS | 34.925 | 76.2 | 17.46 | 1.1 | 25.5 | 13.7 |
| RLS12 | RLS12ZZ | RLS12-2RS | 38.1 | 82.55 | 19.05 | 1.1 | 30.7 | 16.6 |
| RLS13 | RLS13ZZ | RLS13-2RS | 41.275 | 88.9 | 19.05 | 1.1 | 33.2 | 18.6 |
| RLS14 | RLS14ZZ | RLS14-2RS | 44.45 | 95.25 | 20.64 | 1.5 | 35.1 | 19.6 |
| RLS15 | RLS15ZZ | RLS15-2RS | 47.625 | 101.6 | 20.64 | 1.5 | 43.6 | 25 |
| RLS16 | RLS16ZZ | RLS16-2RS | 50.8 | 101.6 | 20.64 | 1.5 | 43.6 | 25 |
| RLS18 | RLS18ZZ | RLS18-2RS | 57.15 | 114.3 | 22.23 | 1.5 | 47.5 | 28 |
| RLS20 | RLS20ZZ | RLS20-2RS | 63.5 | 127 | 23.81 | 1.5 | 61.8 | 37.5 |
| RLS22 | RLS22ZZ | RLS22-2RS | 69.85 | 133.4 | 23.81 | 1.5 | 66.3 | 40.5 |
| RMS4 | RMS4ZZ | RMS4-2RS | 12.7 | 41.275 | 15.875 | 1 | 11.5 | 5.42 |
| RMS5 | RMS5ZZ | RMS5-2RS | 15.875 | 46.038 | 15.875 | 1 | 13.5 | 6.55 |
| RMS6 | RMS6ZZ | RMS6-2RS | 19.05 | 50.8 | 17.46 | 1.1 | 15.9 | 7.8 |
| RMS7 | RMS7ZZ | RMS7-2RS | 22.225 | 57.15 | 17.46 | 1.1 | 18.6 | 9.15 |
| RMS8 | RMS8ZZ | RMS8-2RS | 25.4 | 63.5 | 19.05 | 1.1 | 22.5 | 11.4 |
| RMS9 | RMS9ZZ | RMS9-2RS | 28.575 | 71.438 | 20.625 | 1.1 | 28.1 | 14.6 |
| RMS10 | RMS10ZZ | RMS10-2RS | 31.75 | 79.375 | 22.225 | 1.5 | 33.2 | 18 |
| RMS11 | RMS11ZZ | RMS11-2RS | 34.925 | 88.9 | 22.225 | 1.5 | 41 | 22.4 |
| RMS12 | RMS12ZZ | RMS12-2RS | 38.1 | 95.25 | 23.81 | 1.5 | 41 | 22.4 |
| RMS13 | RMS13ZZ | RMS13-2RS | 41.275 | 101.6 | 23.81 | 1.5 | 52.7 | 30 |
| RMS14 | RMS14ZZ | RMS14-2RS | 44.45 | 107.95 | 26.99 | 2 | 61.8 | 36 |
| RMS15 | RMS15ZZ | RMS15-2RS | 47.625 | 114.3 | 26.99 | 2 | 61.8 | 36 |
| RMS16 | RMS16ZZ | RMS16-2RS | 50.8 | 114.3 | 26.99 | 2 | 61.8 | 36 |
| RMS18 | RMS18ZZ | RMS18-2RS | 57.15 | 127 | 31.75 | 2 | 81.9 | 48 |
| RMS20 | RMS20ZZ | RMS20-2RS | 63.5 | 139.7 | 31.75 | 2 | 92.3 | 56 |
Detailed Bearing Pictures:
Our Main Products:
1,Ball bearings:
(1)Deep groove ball bearings
(2)Thrust ball bearings
(3)Self-Aligning ball bearings
(4)Angular contact ball bearings
2,Roller bearings:
(1)Spherical roller bearings
(2)Thrust roller bearings
(3)Cylindrical roller bearings
(4)Tapered roller bearings.
3,Linear bearings
4,Rod end bearings
5,Slewing bearings
6,Pillow block bearings
7,Needle roller bearings.
8,Adapter Sleeve
9,Eccentric bearings
10,Insert bearings
11,Spindle bearings
12,High precision bearings
