Radial Load RMS18 RMS22 RMS36 RMS48 RMS56 RMS68 Non-Standard Ball Bearings
Price:
Talk in the letter
MOQ:
1 pcs
Delivery Time:
5-7Days After Details Confirmed
Brand:
NSK / KSM / INA / KOYO / OEM
Product Description
Radial Load RMS18 RMS22 RMS36 RMS48 RMS56 RMS68 Non-Standard Ball Bearings
This Series Bearing List:
| Bearing No. | Dimensions | Load Ratings | ||||||
| Open | ZZ | 2RS | d | D | B | r | Dynamic | Static |
| RLS4 | RLS4ZZ | RLS4-2RS | 12.7 | 33.338 | 9.525 | 0.6 | 6.82 | 3.05 |
| RLS5 | RLS5ZZ | RLS5-2RS | 15.875 | 39.688 | 11.112 | 0.6 | 7.65 | 3.72 |
| RLS6 | RLS6ZZ | RLS6-2RS | 19.05 | 47.625 | 14.288 | 1 | 12.8 | 6.65 |
| RLS7 | RLS7ZZ | RLS7-2RS | 22.225 | 50.8 | 14.288 | 1 | 12.8 | 6.65 |
| RLS8 | RLS8ZZ | RLS8-2RS | 25.4 | 57.15 | 15.875 | 1 | 14 | 7.88 |
| RLS9 | RLS9ZZ | RLS9-2RS | 28.575 | 63.5 | 15.875 | 1 | 19.5 | 10 |
| RLS10 | RLS10ZZ | RLS10-2RS | 31.75 | 69.85 | 17.46 | 1.1 | 22.5 | 11.8 |
| RLS11 | RLS11ZZ | RLS11-2RS | 34.925 | 76.2 | 17.46 | 1.1 | 25.5 | 13.7 |
| RLS12 | RLS12ZZ | RLS12-2RS | 38.1 | 82.55 | 19.05 | 1.1 | 30.7 | 16.6 |
| RLS13 | RLS13ZZ | RLS13-2RS | 41.275 | 88.9 | 19.05 | 1.1 | 33.2 | 18.6 |
| RLS14 | RLS14ZZ | RLS14-2RS | 44.45 | 95.25 | 20.64 | 1.5 | 35.1 | 19.6 |
| RLS15 | RLS15ZZ | RLS15-2RS | 47.625 | 101.6 | 20.64 | 1.5 | 43.6 | 25 |
| RLS16 | RLS16ZZ | RLS16-2RS | 50.8 | 101.6 | 20.64 | 1.5 | 43.6 | 25 |
| RLS18 | RLS18ZZ | RLS18-2RS | 57.15 | 114.3 | 22.23 | 1.5 | 47.5 | 28 |
| RLS20 | RLS20ZZ | RLS20-2RS | 63.5 | 127 | 23.81 | 1.5 | 61.8 | 37.5 |
| RLS22 | RLS22ZZ | RLS22-2RS | 69.85 | 133.4 | 23.81 | 1.5 | 66.3 | 40.5 |
| RMS4 | RMS4ZZ | RMS4-2RS | 12.7 | 41.275 | 15.875 | 1 | 11.5 | 5.42 |
| RMS5 | RMS5ZZ | RMS5-2RS | 15.875 | 46.038 | 15.875 | 1 | 13.5 | 6.55 |
| RMS6 | RMS6ZZ | RMS6-2RS | 19.05 | 50.8 | 17.46 | 1.1 | 15.9 | 7.8 |
| RMS7 | RMS7ZZ | RMS7-2RS | 22.225 | 57.15 | 17.46 | 1.1 | 18.6 | 9.15 |
| RMS8 | RMS8ZZ | RMS8-2RS | 25.4 | 63.5 | 19.05 | 1.1 | 22.5 | 11.4 |
| RMS9 | RMS9ZZ | RMS9-2RS | 28.575 | 71.438 | 20.625 | 1.1 | 28.1 | 14.6 |
| RMS10 | RMS10ZZ | RMS10-2RS | 31.75 | 79.375 | 22.225 | 1.5 | 33.2 | 18 |
| RMS11 | RMS11ZZ | RMS11-2RS | 34.925 | 88.9 | 22.225 | 1.5 | 41 | 22.4 |
| RMS12 | RMS12ZZ | RMS12-2RS | 38.1 | 95.25 | 23.81 | 1.5 | 41 | 22.4 |
| RMS13 | RMS13ZZ | RMS13-2RS | 41.275 | 101.6 | 23.81 | 1.5 | 52.7 | 30 |
| RMS14 | RMS14ZZ | RMS14-2RS | 44.45 | 107.95 | 26.99 | 2 | 61.8 | 36 |
| RMS15 | RMS15ZZ | RMS15-2RS | 47.625 | 114.3 | 26.99 | 2 | 61.8 | 36 |
| RMS16 | RMS16ZZ | RMS16-2RS | 50.8 | 114.3 | 26.99 | 2 | 61.8 | 36 |
| RMS18 | RMS18ZZ | RMS18-2RS | 57.15 | 127 | 31.75 | 2 | 81.9 | 48 |
| RMS20 | RMS20ZZ | RMS20-2RS | 63.5 | 139.7 | 31.75 | 2 | 92.3 | 56 |
RMS56 Drawing and Specification :
| Model Number | RMS56 |
| Part Name | Deep Groove Ball Bearing |
| Row | Single Row |
| Dimensions(mm)(d*D*b) | 177.8mm ×342.9mm ×63.5mm |
| Weight / Mass ( KG ) | 27.5kg |
| Precision Rating | ABEC-3 / ABEC-5 |
| Brand | NSK / KSM / INA / KOYO / OEM |
| Original Country Show | CHINA |
| HS Code | 8482800000 |
RMS56 Bearing Detailed Pictures :
Our other Hot Sale Bearings
| Hot Sales in our company |
| 1. deep groove ball bearing 6000,6200,6300,6400,61800,61900,Z,RS,ZZ,2RS |
| 2. spherical roller bearing 22200,22300,23000,24000,23100,24100,CA,CC,E,W33 |
| 3. cylindrical roller bearingN,NU,NJ,NN,NUP,E,ECP,ECM,ECJ |
| 4. taper roller bearing 30200,30300,32200,32300,31300,32000 |
| 5. Aligning ball bearing 1200,1300,2200,2300, |
| 6. needle roller bearing NA,NAV,NK,NKI,RNA,NK,RNAV,ZKLF,ZKLN,ZARF,ZARN |
| 7. thrust ball bearing 51100,51200,51300,51400,E,M |
| 8. angular contact ball bearing7000,7100,7200,7300,AC,BECBM,C |
| 9. spherical plain bearing GE,GEG,GEEW,U,UC,UG,GX,GAC,SA,SABP |
