5 Million Cycles Fencing vehicle barrier gates , car park gates Access Control

5 Million Cycles Fencing vehicle barrier gates , car park gates Access Control

      Wonsun Traffic barrier gate provides a secure and convenient solution of stopping unauthorized vehicle          or giving access to authorized vehicle especially at apartment , for parking lots with high traffic flow such as            toll gate, shopping center, exhibition center, hospitals, airports etc.

• Features:

       1)Manual release

       2)Machine core with compression spring,effectively avoids the accidents caused by spring breaking

       3)Die-casting alumium alloy motor,precision and good at thermal radiating

       4)Motor cooling fan,solving the problem of heating-protection

       5)Double safety limit swithes(photoelectricity limit switch/motor memory sensor)

       6)Reversing on obstacle

       7)Auto-closing

       8)Suport the Infrarer photocell for anyi-bumping function(optional)

       9)Support the external and internal VEHICLE LOOP DETECTOR (optional)

      10) Traffic light interface

      11) Wire control (switch signal)/ Remote control (418MHZ)

      12) RS485 communication module (optional)

• Specifications

  Name	traffic barrier gate
  Speed Time	1.8s/3s/6s
  Arm Type	straight arm,fence arm,folding arm
  Voltage	AC110/220V,50/60HZ
  Remote control	≤30 meter
  Housing material	2.0mm thickness clod rolled steel sheet
  IP level	IP54
  Net weight	55 KG
  Operating temperature	-25°c -55°c
  Humidity	10%-95%

• Applications:
