Speed Adjustable Car Park Barriers Auto Reverse DC Brushless Motor With Traffic Light
Speed Adjustable Auto Reverse DC Brushless Barrier Car Park Barriers Compatible With Traffic Light
Car Park Barriers Parameter:
1. Working temperature(motor): -30℃~+70℃
2 Rated voltage:DC24V
3 Running speed:1.5s-8s
4 Rated current:9.5A
5 Rated power:160W
6 No-load speed:1850rpm
7 Rated speed:1400rpm
8 Rated torque:59.6N.m
9 Relative humidity:≥85%
10 Remote control distance:≤100M(in the open place)
11 IP Degree:IP44
12 Max length of arm:6M
Function setting parameter table
| Menu code | Parameter Scale | Parameter name | Default | Unit | Remark |
| H00-00 | 25-95 | Open speed adjustment | 40 |
Corresponding PWM duty |
|
| H00-01 | 25-95 | Close speed adjustment | 40 |
Corresponding PWM duty cycle |
|
| H00-02 | 5-40 | Open in place decelerate angle | 35 |
The larger the angle value, the |
|
| H00-03 | 5-40 | Close in place decelerate angle | 35 |
The larger the angle value, the |
|
| H00-04 | 1-20 | Open accelerate adjustment | 1 | ms |
The smaller the number, the |
| H00-05 | 1-20 | Close accelerate adjustment | 8 | ms |
The smaller the number, the |
Fault code:
| EFF01:Hall error | Check motor or wiring connection |
Generally, the motor or motor |
| EFF02.Under-voltage fault | The voltage is lower than 22.0V |
Power supply or the battery |
| EFF03.Over current protection |
The load is too heavy or the drive |
Check whether the motor |
|
EFF04.Locked rotation |
The limit has not been reached in place |
Reset the limit point, or |
Arm length and speed comparison table
|
Menu code Parameter Arm length |
UP ARM | DOWN ARM | ||||
| H00-00 | H00-02 | H00-04 | H00-01 | H00-03 | H00-05 | |
| Medium Octagonal arm 3m 1.8s(without rubber) | 95 | 30 | 8 | 95 | 30 | 8 |
| Medium Octagonal arm 3m1.8s(with rubber) | 95 | 25 | 8 | 95 | 25 | 8 |
| Large Octagonal arm 4.5m 3s(without rubber) | 45 | 30 | 10 | 45 | 30 | 10 |
| Large Octagonal arm 6m 5s(with rubber) | 35 | 40 | 10 | 35 | 40 | 10 |
| 3m round arm 1.8s | 95 | 25 | 8 | 95 | 25 | 8 |
(the parameter is based on the company’s arm)
Car Park Barriers Product Maintenance
10.1 Keep the barrier gate clean
10.2 Check the joints ever month in case of any loose parts.
10.3 Check the spring elasticity after the barrier gate running 3000 times.
10.4 Check the easily worn-out parts(like the spring,limit switch),every half year and renew it.
10.5 Remote control distance will be shortened or not work in case like big object screening,battery exhausting,extreme weathers.
