Cold Rolled Sheet Driveway Barrier Gates DC Brushless Motor For Parking Lot
OEM Cold-rolled Sheet DC brushless Motor Driveway Barrier Gates For Parking Lot Management System
Safety Precautions
To ensure your safe operation, please strictly in accordance with the provisions of this manual.
- To avoid personal injury, it is strictly forbidden to open the door or cover when barrier working.
- The barrier housing must be connected to the ground to prevent inductive electric shock.
- It is strictly forbidden to stand, walk or place objects under the boom/ arm when barrier working.
- The boom/arm and the spring have been matched to the balance state before goods leave out our factory. To avoid the danger of the balance being lost, the length and weight of the boom/arm can not be increased or decreased at random. If you need to change it, please ask the professional for advice.
Quick details:
1 Working temperature(motor): -35℃~+85℃
2 Rated voltage:DC24V
3 Running speed:1.5s-8s
4 Rated power:140W
5 Relative humidity:≤90%
6 Remote control distance:≤100M(in the open place)
7 IP Degree:IP44
8 Max length of arm:6M straight arm
Features:
1 The running speed can be adjusted from 1.5s to 8s
2 Can be quickly interchanged
3 Open the barrier gate by motor wheel when power off ,automatically reset after power on
4 Curved crank arm three- link movement structure, the operation is stable
5 Wireless remote control control open/close
6 Auto reverse function(force adjustable)
Function setting parameter table
| Menu code | Parameter Name | Parameter scale | Default | Unit | Remark |
| H00-00 | Open speed adjustment | 25-95 | 40 | Corresponding PWM duty cycle 25%-95%, step size is 1 | |
| H00-01 | Close speed adjustment | 25-95 | 40 | Corresponding PWM duty cycle 25%-95%, step size is 1 | |
| H00-02 | Open in place decelerate angle | 5-40 | 35 | The larger the angle value, the less likely it is to shake the arm when it is in place. | |
| H00-03 | Close in place decelerate angle | 5-40 | 35 | The larger the angle value, the less likely it is to shake the arm when it is in place. | |
| H00-04 | Open accelerate adjustment | 1-20 | 1 | ms | The smaller the number, the faster the speed |
| H00-05 | Close accelerate adjustment | 1-20 | 8 | ms | The smaller the number, the faster the speed |
| H00-06 | Open in place angle | 1-30 | 1 | degree | step size is 1 |
The parameter for selecting the balance compressed spring
| Number | The length of boom (L=meter) | Diameter of the spring (D=mm) | Link hole selection |
| 1 | 2.5＜L＜3.5 | D=4.5 | Link hole 2 |
| 2 | 3.5≤L≤4.0 | D=5.5 | Link hole 1 |
| 3 | 4.0＜L＜5.5 | D=6.5 | Link hole 2 |
| 4 | 5.5≤L≤6.0 | D=6.5 | Link hole 1 |
RFQ:
Q: What's the order process?
A: Follow the steps on below to complete your order.
- 1. Inquiry
Provide us detailed information about your requirement, and we'll recommend the suitable products according to your request
-2. Quotation
Official quotation form with all clear specifications according to the order
-3. Invoice
Invoice will be issued once the quotation is confirmed.
-4. Payment
Payment shall be issued once the invoice issued. Full payment is acquired.
-5. Production
Bulk production shall be taking 15-25 working days.
-6. Delivery
by sea, air or courier. Detailed picture of package will be provided upon the service you've chosen. Packaging info will be sent upon confirmation.
Learning type remote control
The remote control using special IC learning code remote controller, 418MHz wireless frequency, strong anti-interference, long remote control distance, that can up to 100meters in good weather, use easily and durable. The receiver of learning code remote control can store 16 different remote control codes, and support unlimited number of same code remote control. The external receiver learned the remote control within 5 seconds when power on,press the open/close key at the same time to complete the learning, and reset to continue learn when not complete. If repeat the learning, open the external receiver shell, there is a white button on circuit board, hold down 15 seconds to delete the remote control code, continue to learn or press the white button to learn.
Service Items
1 One year’s free servicing is supplied(not including the arm);
2 Lifetime charged servicing is offered;
3 Technology servicing is supplied.
The following situations are charged for servicing(or changing):
1Broken by the wrong installation.
2Broken by improper voltage.
3The surfaces of the system destroyed by wrong installation or use.
4Broken by natural disaster.
5Overdue.
6Servicing items out of our promises.
