SC LC Fiber Optic Patch Cord 2.0mm Anti rodent / Harsh Environment fiber optic jumper​
Armored fiber optic patch cord are used in indoor applications in customer premises, central offices and in harsh environments. The patch cord provide flexible interconnection to active equipment, passive optical devices and cross-connects. Armored patch cord are constructed with a stainless steel tube over a standard patch cord surrounded by a stainless steel mesh with an outer jacket. They are terminated with standard range of connectors, all quality tested to international standards.

Armored optic fiber patch cord and traditional fiber optic patchcord the biggest difference is that it uses a small bypass pipe and a woven metal mesh to protect the optical fiber according to fiber easy broken, easy damage defects, and flame retardant PVC protective sheath, in order to achieve the purpose of moistureproof fireproof and prevention of rat bite. It can be directly laid in the network room and other harsh environments, without the use of protective sleeves for saving space.

Armored cable structure as follows: 0.6mm tightly fiber + metal hose + Dupont Kevlar

+ woven metal wire ( reinforced cable torsion function, to prevent external damage

to cable ) + environmental flame retardant PVC, than cable strength greater than the

general indoor cable. It Can prevent rat bite, compressive, tensile, meet the harsh

working environment. Greatly enhance the network maintenance convenience.

Features

Security, Stability and Reliable, Low Insertion Loss, High Return Loss

Single Mode and Multi-mode(50/125μm, 62.5/125μm) Cable Jumpers/Pigtails are Available

Single and Duplex are Available

Cable Diameter:φ3.0mm, φ3.3mm

With a Micro diameter stainless steel tube for protection
Resist destroy by improper twist

High resistance of tensile, pressure, rodent bite
More convenient to deploy and ensure safety
Without damage by construction
No need to worry about destroy in the future
Reduce the maintenance cost afterwards


Specifications
