2000kg Passenger High Speed Elevator For Airport Building Lifts Elevators
Passenger High Speed Elevator For Airport , Building Lifts Elevators Load 320~2000kg
| ·Passenger Elevator Series Machine Roomless |
| ·Stable, low running noise, comfortable, eco-efficiency, automatic error recording |
| ·Adopts the three advanced technologies: synchronous permanent-magnetic (SPM) gearless traction machine, microcomputer serial communication system and variable voltage variable frequency control (VVVF) |
| ·Traction machine is just half size of the traditional one, but better driving efficiency with lower motor power. The running noise and vibration is greatly reduced because of abandon of worm gear. |
| ·Minimum machine room design and machine roomless design save most of the building space, improve the usage percentage. |
Passenger elevator with mini machine room technology parameter
| Load(kg) | Person | Speed(m/s) | Car size(mm) | Door open(mm) | Shaft size(mm) | OH(mm) | PD(mm) | Power(kw) |
| 320 | 4 | 1.0 | 950*940*2500 | 700*2100 | 1600*1650 | 4550 | 1400 | 2.1 |
| 400 | 5 | 1.0 | 1050*1050*2500 | 700*2100 | 1800*1750 | 4550 | 1400 | 2.7 |
| 450 | 6 | 1.0/1.5/1.6/1.75 | 1150*1050*2500 | 800*2100 | 1900*1800 | 4550/4600/4600/4700 | 1400/1500/1500/1600 | 3/4.5/4.8/5.2 |
| 630 | 8 | 1.0/1.5/1.6/1.75 | 1400*1100*2500 | 800*2100 | 2000*1800 | 4550/4600/4600/4700 | 1400/1500/1500/1600 | 4.2/6.3/6.7/7.3 |
| 800 | 10 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1400*1350*2500 | 800*2100 | 2000*2050 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 5.3/8.5/9.3/10.9/13.6/17/20.4/20.4 |
| 1000 | 13 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1600*1400*2500 | 900*2100 | 2200*2100 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 6.6/10.5/11.6/13.3/16.6/20/26.7/26.7 |
| 1050 | 14 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1600*1500*2500 | 900*2100 | 2200*2200 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 7/11.2/12.2/14/17.5/20/26.7/26.7 |
| 1150 | 15 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1700*1500*2500 | 1000*2100 | 2300*2200 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 7.6/12.2/13.4/15.3/19.1/23.7/31.6/31.6 |
| 1250 | 16 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1700*1600*2500 | 1000*2100 | 2300*2300 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 8.3/13.4/14.6/16.7/20.9/25.5/34/34 |
| 1350 | 18 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 1800*1600*2500 | 1000*2100 | 2400*2300 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 9.3/15/16.4/18.7/23.4/27.8/37/37 |
| 1600 | 21 | 1.0/1.6/1.75/2.0/2.5/3.0/3.5/4.0 | 2000*1700*2500 | 1100*2100 | 2700*2600 | 4350/4500/4500/4950/5200/5550/5650/5800 | 1400/1500/1600/1750/1950/4300/4300/4500 | 11.1/16.6/17.7/19.4/22.2/33.3/44.1/44.1 |
| 2000 | 26 | 1.0/1.6/1.75/2.0/2.5 | 1900*2100*2500 | 1200*2100 | 2900*2550 | 4400/4500/4600/4700/4950 | 1500/1600/1700/1750/1950 | 14/22.1/24.4/27.2/34 |
About our hot products:
FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
