Manganin alloy resistance heating wire 6J11 for measuring apparatus
Price:
USD+30USD/KG
MOQ:
20kg
Delivery Time:
10days
Brand:
Tankii
Product Description
Basic Info.
Model NO.
6J11
PCD
120mm
ET
0
Hole
0
State
soft ,hard
surface
bright
standard
GB/ASTM
sample
Free
Size
0.01-10mm
Transport Package
in Roll/Coil/Spool
Specification
0.01-10mm
Trademark
TANKII
Origin
Shanghai, China
HS Code
7409400000
Production Capacity
2000ton/Year
Product Description
Manganin alloy resistance heating wire 6J11 for measuring apparatus
Chemical Content, %
Mechanical Properties
![Manganin alloy resistance heating wire 6J11 for measuring apparatus]()
![Manganin alloy resistance heating wire 6J11 for measuring apparatus]()
![Manganin alloy resistance heating wire 6J11 for measuring apparatus]()
![Manganin alloy resistance heating wire 6J11 for measuring apparatus]()
![Manganin alloy resistance heating wire 6J11 for measuring apparatus]()
Chemical Content, %
| Ni | Mn | Fe | Si | Cu | Other | RoHS Directive | |||
| CD | Pb | Hg | Cr | ||||||
| - | 10.5-12.5 | - | - | Bal | - | ND | ND | ND | ND |
Mechanical Properties
| Max Continuous Service Temp | 0-45ºC |
| Resisivity at 20ºC | 0.49±0.03ohm mm2/m |
| Density | 8.G/cm3 |
| Temp Coefficient of Resistance at 20 ºC | -80~+80α×10-6/ºC |
| Melting Point | 1450ºC |
| Tensile Strength(Hard) | 635 MPa(min) |
| Tensile Strength,N/mm2 Annealed,Soft | 340~535 |
| Elongation | 15%(min) |
| EMF vs Cu, μV/ºC (0~100ºC) | 2 |
| Micrographic Structure | Austenite |
| Magnetic Property | Non |
| Micrographic Structure | Ferrite |
| Magnetic Property | Magnetic |
