Metco 8400/Ni95al5 / Tafa 75b Thermal Spray Wire For Arc Spraying Nickel Alloy Wire

Metco 8400/Ni95al5 / Tafa 75b Thermal Spray Wire for Arc Spraying Nickel Alloy Wire

Metco 8400 thermal spray wire is an austenitic nickel-aluminium alloy (NiAl alloy) for use in arc and flame spray systems. The alloy produces dense, well bonding coatings. It is a good kind of thermal spray wire.Typical applications for metco are bond coats, as protective coatings against high-temperature oxidation, protective coatings against scaling of conventional iron base alloys and as build-up coatings for dimensional restoration.
 Chemical Composition: Ni ~ 95, Al ~ 5
Application or Properties: Spray wire with excellent bonding strength. Sprayed layers of this material are-resistant to variation in high temperatures and are used as a buffer layer for all other spraying alloys. Hardness, coating macro: Approximately HRc 22. Maximum working temperature: Approximately 800° C. Layer thickness: Approximately 0.1-0.15 mm.
NiAl 95/5 diameter 1.6mm
 Technical Index
 1 Coating Hardness: 23~25 HRC
 2 Bond Strength: 60Mpa above
 3 Working Temperature: 1250 °C below

Typical Deposit Characteristics:

Standard Sizes & Packing:
