FeCr13Al4 Alloy Wire 0.05-5.0mm for Water Heaters

Price Negotiable

Price: USD4-6/kg

MOQ: 10kg

Delivery Time: 10-15Days

Brand: tankii

Product Description

Fecr13al4 Alloy 125 Ferritic Alloy Fecral13/4 Wire For Water Heater

Product Specifications

Attribute	Value
Shape	Wire / Strip / Ribbon
Diameter	0.05-5.0mm

Product Description

FeCrAl resistance electrothermal alloy features high resistivity, excellent surface oxidation resistance, high temperature strength, superior processing performance, and weldability. This material is widely used in industrial, household appliance, and machinery manufacturing applications as heating elements and resistance materials.

Chemical Composition

GRADE	Chemical Composition
0Cr15Al5	Cr: 14.5-15.5 \| P: 0.12 \| S: 0.025 \| Mn: 0.7 \| Si: ≤1.00 \| Ni: 5.0-7.0 \| Al: 4.5-5.3 \| Fe: Rest

Applications of FeCrAl

Application	Advantages
Automobile and motorcycle exhaust purification metal honeycomb carrier	Uniform chemical composition, high resistivity, long service life
Locomotive starting and brake resistor	High temperature resistance, durability
Temperature detection, drilling oil field brake resistor	Stable performance in harsh environments
Grounding resistance cabinet for power systems	Reliable electrical properties
Cement resistance, sealing machines, electronic industry components	Versatile industrial applications

Material Properties

Properties	1Cr13Al4	0Cr25Al5	0Cr21Al6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
Cr (%)	12.0-15.0	23.0-26.0	19.0-22.0	22.5-24.5	18.0-21.0	21.0-23.0	26.5-27.8
Al (%)	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.0	3.0-4.2	5.0-7.0	6.0-7.0
Max Service Temp (°C)	950	1250	1250	1250	1100	1350	1400
Resistivity (Ωmm²/m)	1.25±0.08	1.42±0.06	1.42±0.07	1.35±0.07	1.23±0.07	1.45±0.07	1.53±0.07
Tensile Strength (N/mm²)	580-680	630-780	630-780	630-780	600-700	650-800	680-830
