K Type Thermocouple Wire Chromel Alumel KP KN 0.01~12mm
Price:
20 usd/kg
MOQ:
15KG
Delivery Time:
15DAYS
Brand:
TANKII
Product Description
Basic Info.
Model NO.
K
Application
Heating
Conductor Material
Chromel Alumel
Sheath Material
Bare
Insulation Material
Bare
Material Shape
Round Wire
Range of Application
Flame Retardant
Certification
ISO9001
Brand
Tankii
Surface
Bright/ oxidized
Dia
0.3/0.5/0.8/1.0/1.2/1.6/2.0/2.5/3.2mmm
Condition
Bright, Annealed, Soft
Diameter
0.012-8mm
shape
round, ribbon, strip, rods
SGS
yes
RoHS
yes
MTC
yes
Free sample
yes
Item
K type thermocouple wire chromel alumel KP KN 0.01
Transport Package
Spool, Carton, Wooden Box
Specification
0.3/0.5/0.8/1.0/1.2/1.6/2.0/2.5/3.2mm
Trademark
TANKII
Origin
China
HS Code
7505220000
Production Capacity
50 Tons/Month
Product Description
K type thermocouple wire chromel alumel KP KN 0.01~12mm (type K KCA KCB KPX KNX)
Product Description
Tankii NiCr-Ni(Type K) thermocouple finds the widest use in all basemetal thermocouple, at temperature above 500 °C.
Type K thermocouple has strong resistance to oxidation than other base metal thermocouples. It has high EMF against Platinum 67, excellent temperature accuracy, sensitivity and stability, with a low cost. It is recommended for oxidizing or inert atmospheres, but cannot be used directly in the following cases:
(1) Alternatively oxidizing and reducing atmosphere.
(2) Atmosphere with sulphur gases.
(3) Long time in vacuum.
(4) Low oxidizing atmosphere such as hydrogen and carbon monoxide atmosphere.
Detailed Parameter
|
Chemical Composition
|
|||||
Conductor Name |
Polarity |
Code |
Nominal Chemical Composition /% |
||
Ni |
Cr |
Si |
|||
Ni-Cr |
Positive |
KP |
90 |
10 |
-- |
Ni- Si |
Negative |
KN |
97 |
-- |
3 |
|
Working Temperature
|
||
| Diameter/mm | Long time Working temperature /ºC |
Short period Working temperature /ºC |
0.3 |
700 |
800 |
0.5 |
800 |
900 |
0.8,1.0 |
900 |
1000 |
1.2,1.6 |
1000 |
1100 |
2.0,2.5 |
1100 |
1200 |
3.2 |
1200 |
1300 |
Thermocouple wire's Application:
1. Heating - Gas burners for ovens
2. Cooling - Freezers
3. Engine protection - Temperatures and surface temperatures
4. High temperature control - Iron casting
