0.35mm 0.8mm 1.0mm Permalloy Strip/Plate Used In Magnetic Resonance Imaging (MRI) Equipment
Price:
USD35~45/kg
MOQ:
100 kg
Delivery Time:
15-35 days after gettting the payment
Brand:
Tankii
Product Description
0.35mm 0.8mm 1.0mm Permalloy Strip/Plate Used In Magnetic Resonance Imaging (MRI) Equipment
Permalloy, also known as iron nickel alloy, has a wide range of nickel content, between 35% and 90%.
The biggest characteristic of Permalloy is its high weak magnetic field permeability.
Their saturation magnetic induction intensity is generally between 0.6-1.0T.
Tankii Group can produce permalloy strip/lplate/wire/rod based on customer's request.
Chemical composition
| Composition | C | P | S | Mn | Si |
| ≤ | |||||
| Content(%) | 0.03 | 0.02 | 0.02 | 0.3~0.6 | 0.15~0.3 |
| composition | Ni | Cr | Mo | Cu | Fe |
| Content(%) | 79.0~81.0 | - | 4.8~5.2 | ≤0.2 | Bal |
Heat treatment system
| Tankii Grade | Annealing medium | heating temperature | Keep the temperature time/h | Cooling rate |
Tankii 111-85 |
Dry hydrogen or vacuum, pressure is not greater than 0.1 Pa | Along with the furnace heating up 1100~1150ºC | 3~6 |
In 100 ~ 200 ºC / h speed cooling to 600 ºC, fast to 300 ºC draw a charge |
Available Shape
| Alloys Name | Type | Dimension | ||
Tankii 111-85 |
Wire | D= 0.05~8mm | ||
Tankii 111-85 |
Strip | W= 8~390mm | T≥ 0.1mm | |
Tankii 111-85 |
Foil | W= 10~100mm | T= 0.01~0.1 | |
Tankii 111-85 |
Bar | Dia= 8~100mm | L= 50~1000 | |
Soft magnetic alloy outer magnetic field under the action of easy magnetization, basic disappear after removal of magnetic field of magnetic induction intensity and magnetic alloys.
Application:
Typical application scenarios:
Based on its high magnetic permeability characteristics, permalloy Tankii 111-85 is mainly used for:
Weak magnetic field equipment: high-frequency magnetic head, current transformer, magnetic shielding.
Precision components: sensors, relays, small transformer cores.
Magnetic Shielding:
-
Micro precision current transformer
Package:
1). Coil (plastic spool) + compressed ply-wooden case + pallet
2). Coil (plastic spool) + carton + pallet
2). Coil (plastic spool) + carton + pallet
