High Purity Nickel Sheet / Nickel Foil / Nickel Strip (Ni 200/201)
Price:
25-35USD/Kg
MOQ:
5Kg
Delivery Time:
20-25days
Brand:
Tankii
Product Description
High Purity Nickel Sheet / Nickel Foil / Nickel Strip (Ni 200/201)
1. Product Overview
Pure nickel foil is a high-purity nickel material with excellent electrical conductivity, corrosion resistance, and high-temperature stability. It is widely used in new energy batteries, electronic components, aerospace, and chemical industries.
2. Main Grades & Standards
| Grade | Standard | Nickel Content | Characteristics |
|---|---|---|---|
| N4 | GB/T 5235-2020 | ≥99.9% | High purity, low carbon |
| N6 | GB/T 5235-2020 | ≥99.5% | Commercial pure nickel, general purpose |
| Ni200 | ASTM B162 / UNS N02200 | ≥99.5% | Excellent corrosion resistance |
| Ni201 | ASTM B162 / UNS N02201 | ≥99.5% | Low-carbon version for high-temp applications |
| Nickel 270 | DIN 17740 | ≥99.95% | Ultra-high purity |
Technical Standards: Chemical composition per GB/T 5235-2021, foil standards GB/T 2072-2020, YS/T 522-2010, ASTM F3, DIN 17740.
3. Product Specifications
Electrodeposited Nickel Foil
-
Thickness: 0.005～0.05mm
-
Width: 80～1330mm
-
Features: Ultra-thin, surface roughening available (Ra ≥1.5μm)
Rolled Nickel Foil
-
Thickness: 0.02～0.1mm (up to 1.0mm available)
-
Width: 1.5～420/740/927mm
-
Temper: Soft (M), Quarter-hard (1/4H), Half-hard (1/2H), Three-quarter-hard (3/4H), Hard (H)
4. Key Application Fields
| Application Field | Specific Uses |
|---|---|
| New Energy Batteries | Lithium-ion & Ni-MH battery electrodes, current collectors |
| Electronics | EMI shielding, touch screens, specialty transformers, resistors, capacitors |
| Aerospace | Engine combustion chambers, turbine blades, spacecraft shells |
| Chemical Equipment | Corrosion-resistant vessels, pipelines, valves, heat exchangers |
| Precision Instruments | Thermocouples, high-temp sensors, medical devices |
| Others | Hot stamping, loudspeakers, graphite gaskets |
5. Product Advantages
-
High Purity: 99.5%-99.99% nickel content, strict impurity control
-
Excellent Conductivity: Low resistivity, ideal for battery current collectors
-
Corrosion Resistance: Outstanding performance in alkaline and neutral environments
-
High-Temperature Stability: Melting point 1446°C, stable mechanical properties at high temps
-
Good Workability: Suitable for stamping, bending, welding, and other secondary processing
-
Customizable: Non-standard sizes, surface roughening, special packaging available
