Enameled Nichrome Alloy Wire Ni80Cr20 Nichrome 0.02-1.5mm Golden yellow Red for High/Low Voltage Resistors
Price:
USD30/kg
MOQ:
10kg
Delivery Time:
10-15Days
Brand:
tankii
Product Description
Enameled Nichrome Alloy/ Copper Alloy Wire CuNi23 Resistance Alloy
These enameled resistance wires have been broadly used for standard resistors, High /Low Voltage Resistor automobile parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.
Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.
Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.
Product Specifications
| Attribute | Value |
|---|---|
| Size | 0.02-1.5mm |
| Color | Golden yellow, Red, etc. |
Product Description
High-quality enameled Ni80Cr20 Nichrome 80/20 NiCr resistance alloy wire designed for precision applications requiring stable electrical resistance and thermal performance.
Type of Insulation
| Insulation-enamelled Name | Thermal LevelºC (working time 2000h) | Code Name | GB Code | ANSI TYPE |
|---|---|---|---|---|
| Polyurethane enamelled wire | 130 | UEW | QA | MW75C |
| Polyester enamelled wire | 155 | PEW | QZ | MW5C |
| Polyester-imide enamelled wire | 180 | EIW | QZY | MW30C |
| Polyester-imide and polyamide-imide double coated enameled wire | 200 | EIWH (DFWF) | QZY/XY | MW35C |
| Polyamide-imide enamelled wire | 220 | AIW | QXY | MW81C |
Dimension of Insulation
| D mm | Min thickness of insulation | Max OD of Enameled | ||
|---|---|---|---|---|
| I | II | I | II | |
| 0.02 | 0.005 | 0.009 | 0.09 | 0.036 |
| 0.022 | 0.005 | 0.019 | 0.032 | 0.038 |
| 0.025 | 0.006 | 0.010 | 0.036 | 0.042 |
| 1.500 | 0.059 | 0.090 | 1.605 | 1.654 |
Product Images
