Ni80Cr20 Heating Resistance Strip Roll – 0.1-5mm x 5-200mm High Resistivity Nichrome Strip for Furnace & Heater Manufacturing up to 1200°C
Price:
negotiable
MOQ:
10kg
Delivery Time:
15-20days
Brand:
Tankii
Product Description
Ni80Cr20 nichrome strip sealing wire for using with vacuum sealing machine
Nickel-chromium alloy, nickel chromium iron alloy with high resistivity, surface oxidation resistance is good, and have higher strength at high temperature, good processability and weldability, which can be widely used in metallurgy, electrical appliances, machinery manufacturing, etc do resistance material heating elements and electrical industry.
Nickel chrome Ni80Cr20 Electrical resistivity of alloy main technical performance
| brand | Cr | Ni | Al | Fe | C | P | S | Mn | Si |
| ≤ | |||||||||
| Ni80Cr20 | 20.0~23.0 | Remain | ≤0.5 | ≤1 | 0.08 | 0.02 | 0.15 | 0.60 | 0.75~1.6 |
| brand | highest use temperature/ºC | Melting point/ºC | density (g/cm³) | resistivity/(μΩ·M) | elongation(%) | Coefficient of thermal conductivity | Linear expansion coefficient of | microstructure | magnetic |
| Ni80Cr20 | 1200 | 1400 | 8.40 | 1.09 | ≥20 | 60.3 | 18.0 | austenitic | no magnetic |
Mechanical properties
| brand | Tensile strength/Mpa |
| Ni80Cr20 | 637~786 |
Use time test
| brand | Test temperature/ºC | time/h |
| Ni80Cr20 | 1200 | 80 |
