CuNi44 Constantan Foil 0.005-0.3mm Ultra-Thin for Thermocouple and Precision Resistor Applications
Price:
negotiable
MOQ:
10kg
Delivery Time:
15-20days
Brand:
Tankii
Product Description
CuNi44 Constantan Foil electrothermal Film
Our company produce alloy foil, metal foil, steel foil thickness 0.005mm-0.1mm(5um-100um), width 1mm-1330mm.
Chemical Content, %
Ni |
Mn |
Fe |
Si |
Cu |
Other |
ROHS Directive |
|||
Cd |
Pb |
Hg |
Cr |
||||||
44 |
1.50% |
0.5 |
- |
Bal |
- |
ND |
ND |
ND |
ND |
Mechanical Properties
Max Continuous Service Temp |
400ºC |
Resisivity at 20ºC |
0.49±5%ohm mm2/m |
Density |
8.9 g/cm3 |
Thermal Conductivity |
-6(Max) |
Melting Point |
1280ºC |
Tensile Strength,N/mm2 Annealed,Soft |
340~535 Mpa |
Tensile Strength,N/mm3 Cold Rolled |
680~1070 Mpa |
Elongation(anneal) |
25%(Min) |
Elongation(cold rolled) |
≥Min)2%(Min) |
EMF vs Cu, μV/ºC (0~100ºC) |
-43 |
Micrographic Structure |
austenite |
Magnetic Property |
Non |
We usually produce constantan foil, nichrome foil, pure nickel foil, FeCrAl alloy foil, resistance foil, NiFe foil, invar foil. Resistohm 135 foil.
If you have any requirement, pls be free to tell us.
Shanghai Tankii Alloy Material Co., Ltd.
