China Stainless Steel Fecral Alloy Wire 0.7mm 0.9mm 1.0mm With Electric Resistance for sale

Stainless Steel Fecral Alloy Wire 0.7mm 0.9mm 1.0mm With Electric Resistance

Price Negotiable

Price: 5-7.5USD/KG

MOQ: 15 KG

Delivery Time: 5-35 DAYS

Brand: Tankii

Product Description

Stainless steel wire 0.7mm 0.9mm 1.0mm fecral alloy wire electric resistance wire

Product Description

ocr13al4, ocr19al3, ocr21al4, ocr25al5, ocr21al6, ocr21al6nb, ocr27al7mo2, ocr23al5
Fecral Heating Resistance Wire

Material composition

1.FeCrAl wire strip includes: OCr13Al4,OCr19Al3,OCr21Al4,OCr20Al5,OCr25Al5,OCr21Al6,OCr21Al6Nb,OCr27Al7Mo2.

2.Nickel chrome wire Strip Bar includes: Cr25Ni20,Cr20Ni35,Cr15Ni60,Cr20Ni80.

3.Copper Nickel wire Strip includes:

CuNi1,CuNi2,CuNi5,CuNi8,CuNi10,CuNi14,CuNi19,CuNi23,CuNi30,CuNi34,CuNi44.

4.Constantan wire includes: 6J40,4J42,4J32.

5.Manganin wire:6J8,6J12,6J13.

FeCrAl:
RESISTOHM 125, RESISTOHM 135, RESISTOHM 140,
RESISTOHM 145, RESISTOHM Y, RESISTOHM E

Grade of FeCrAl	Chemical Content%
C	P	S	Mn	Si	Cr	Ni	Al.	Fe	Re	Other
Max(≤)
1CR13AL4	0.12	0.025	0.025	0.7	≤1,00	12.5-15.0	----	3.5-4.5	0.1	Bal.
0CR15AL5	0.12	0.025	0.025	0.7	≤1,00	14.5-15.5	----	4.5-5.3	0.1	Bal.
0CR25AL5	0.06	0.025	0.025	0.7	≤0,60	23.0-26.0	≤0,60	4.5-6.5	0.1	Bal.
0CR23AL5	0.06	0.025	0.025	0.7	≤0,60	20.5-23.5	≤0,60	4.2-5.3	0.1	Bal.
0CR21AL6	0.06	0.025	0.025	0.7	≤1,00	19.0-22.0	≤0,60	5.0-7.0	0.1	Bal.
0CR21AL4	0.06	0.025	0.025	0.7	≤1,00	21.0-23.0	≤0,60	3.0-5.2	0.1	Bal.
0CR21Al6Nb	0.05	0.025	0.025	0.7	≤0,60	21.0-23.0	≤0,60	5.0-7.0	0.1	Bal.
0CR27Al7MO2	0.05	0.025	0.025	0.7	≤0,40	26.5-27.8	≤0,60	6.0-7.0	0.1	Bal.
