S Type Thermocouple Bare Wire PT And PT90+RH10 Couple Wire Dia 0.25mm
PT And PT90+RH10 Couple Wire Dia 0.25mm Used for S type Thermocouple
Characteristics:
●Excellent thermoelectricity, excellent linear relationship between thermoelectrical potential and the temperature.
●Excellent thermoelectrical stability, high accuracy.
Quick Description
What is thermocouple wire?
Thermocouple wire allows temperatures to be measured electronically.
A typical thermocouple construction consists of a pair of dissimilar metals that are electrically joined together at the sensing point and connected to a voltage measuring instrument at the other end. When one junction is hotter than the other, a thermal “electromotive” force (in millivolts) is produced that is roughly proportional to the difference in temperature between the hot and cold junctions.
The thermocouple wires with different varieties and specifications of our company can be applied in all kinds of thermocouples, the temperature ranges from -270℃ to 1800℃.
The thermocouple wires have excellent performance and are extensively used in the temperature measurement and control in different fields, such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.
Our products conform to the standards of IEC584 -1and IEC-2.
Please contact me if there is inquiry on thermocouple wire or cable.
Characteristics:
●Excellent thermoelectricity, excellent linear relationship between thermoelectrical potential and the temperature.
●Excellent thermoelectrical stability, high accuracy.
2. Cooling – Freezers
3. Engine protection – Temperatures and surface temperatures
|
Thermocouple type and index
|
Measurement Range ℃ |
|
|
Type
|
Index
|
|
|
PtRh30-PtRh6 |
B | 600~1700 |
|
PtRh13-Pt |
R | 0~1600 |
|
PtRh10-Pt |
S | 0~1600 |
|
NiCr-NiSi |
K | -200~1300 |
|
NiCr-CuNi (constantan) |
E | -200~900 |
|
Fe-CuNi (constantan) |
J | -40~750 |
|
Cu-CuNi (constantan) |
T | -200~350 |
|
NiCrSi-NiSi |
N | -200~1300 |
