Resistance 6J23 NiCr20 AISI 2.50mm Thick Nicr Alloy
Tankii Evanohm R, 6J23 NiCr20AlSi, 0.020 - 2.50mm thick, 3.0 - 300mm width, Made in China
Production Description:
NCH1, Resistance Alloy for Resistor , 0.030 - 2.50mm thick, 3.0 - 300mm width, Made in Japan
Eectrical resistance alloys: NCH-1, NCH-2, Evanohm R, CN30, CN49, Manganin, Zeranin30,
Electrical heating alloys: FCH-1, FCH-2, CN10, CN15, TJR-1, TJR-2
The precision of thickness affects the precision of resistance in resistance alloys.
We guarantee a high degree of thickness precision by using different rolling mills for different purposes.
What's more, we are also able to adjust conductor resistance values by utilizing our advanced thickness control capabilities.
| Port | Shanghai,China | fast life(h/℃) | - |
| Brand | tankii | grade | NiCr alloy |
| Ni | bal | application | heating element and resistor |
| max continuous operating temperature(℃) | 300 | powder or not | not powder |
| resistivity(Ω/cmf,20℃) | 1.33 | ltimate strength( ≧mpa) | as standard |
| resisitivity(μΩ/m,60℉) | 800 | type | Nickel Chrome strip |
| density(g/cm³) | 8.1 | surface | bright |
| thermal conductivity(KJ/m·h·℃) | 46 | shape | strip |
| linear expansion coefficient(x10﹣6/℃)20-1000℃ | - | Material | nickel chrome |
| melting point (℃) | 1400 | condition | bright |
| hardness(Hv) | 180 | color | silvery white |
| Elongation(%) | 10-20 | density | 8.1 g/cm3 |
| Micrographic structure | austenite | feature | good form stability |
| Magnetic property | non | MOQ | 100kg |
