UNS K92500 1.4765 Heating Resistance FeCrAl Wire For Infrared Heaters
Price:
5-35 usd/kg
MOQ:
5KG
Delivery Time:
5-30 days
Brand:
Tankii
Product Description
UNS K92500, 1.4765 Heating Resistance Wire For Heating Elements
FeCrAl 0Cr25Al5 resistance heating alloy Applications
Infrared heaters, heating plates, irons, ceramic heaters & pots, fan heaters, quartz tube heaters, toasters, ovens, storage heaters, bead insulated coils, open coil components, hot air guns, convection heaters, radiators, industrial furnaces for heat processing, metal sheath tubular elements, suspended coil elements for air heaters
Heanjia Super-Metals manufactures resistance heating elements for the wide range of applications varying from industrial furnaces to domestic appliances.
Industrial Nomenclatures: UNS K92500, 1.4765
FeCrAl 0Cr25Al5 resistance heating alloy Chemical composition and characteristics
| Elements | |
| Chromium (Cr) | 23 to 26 % |
| Aluminum (Al) | 4.5 to 6.5 % |
| Iron (Fe) | Rem % |
| Properties | |
| Maximum operation temperature | 1250 oC |
| Electric resistivity | 1.42 micro-ohm. Meter at 20 oC |
| Density | 7.10 gram per cm3 |
| Thermal conductivity | 46.1 KJ/m.h.°C |
| Linear coefficient of thermal expansion | 16 x 10-6 per oC |
| Melting Point | 1500 oC |
| Tensile Strength | 630 to 780 Mpa |
| Elongation | Above 12 % |
| Reduction in area | 60 to 75 % |
| Hardness | 200 to 260 HB |
