Ni50Cr14Si 50HXC Precision Alloy Bright Magnetic Saturation Soft Magnetic Alloy
Price:
negotiable
MOQ:
200 KG
Delivery Time:
7-20 days
Brand:
TANKII
Product Description
medium permeability of medium magnetic saturation soft magnetic alloy
This kind of alloy of nickel content in 45% ~ 50%.The saturated magnetic induction intensity from 1 to 1.5 T, higher than that of high permeability alloy under high magnetic saturation alloy, its permeability and coercive force between the two types of alloys.Mainly used for the secondary magnetic field work of all kinds of transformers, relays, electromagnetic clutch, iron core, the resistivity of this kind of alloy of high magnetic full alloy than the high resistivity, and thus can be applied to high frequency.
Chemical composition
| composition | C | P | S | Mn | Si |
| ≤ | |||||
| Content(%) | 0.03 | 0.02 | 0.02 | 0.6~1.1 | 0.10~1.4 |
| composition | Ni | Cr | Mo | Cu | Fe |
| Content(%) | 49.5~51.0 | 3.8~4.2 | - | 0.2 | Bal |
Physical properties
| Shop sign | Linear expansion coefficient | Resistivity (μΩ·m) |
Density (g/cm³) |
Curie point (ºC) |
Saturation magnetostriction coefficient (10-6) |
| 1j54 | 9.20 | 0.9 | 8.2 | 360 | - |
Heat treatment system
| shop sign | Annealing medium | heating temperature | Keep the temperature time/h | Cooling rate |
1j54 |
Dry hydrogen or vacuum, pressure is not greater than 0.1 Pa | Along with the furnace heating up 1100~1150ºC | 3~6 |
In 100 ~ 200 ºC / h speed cooling to 600 ºC, fast to 300 ºC draw a charge |
Soft magnetic alloy are in weak magnetic field with high permeability and low coercive force of alloys.This kind of alloy are widely used in radio electronics, precision instruments and meters, remote control and automatic control system, the combination is mainly used for energy conversion and information processing, the two aspects of is an important material in the national economy.
