Round Nicr Alloy Rod Chromel For Braking Resistor D/ NiCr3020
Price:
Negotiable
MOQ:
20kg
Delivery Time:
Negotiable
Brand:
TANKII
Product Description
NiCr3020 / Ni30Cr20 Nichrome Alloy Rod for Braking Resistor
1.About Nichrome Ni30Cr20 Rod
Nichrome alloy Ni35Cr20 characterized by high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability. It is suitable for use at temperatures up to 1100°C.2.Ni30Cr20 has many other Grade name:
Cr20Ni35, Chromel D, Nikrothal 40, N4, Chromax, HAI-NiCr 40, Tophet D, Resistohm 40, Cronifer III, 35-20 Ni-Cr, Alloy D, Nikrothal 40, MWS-610, Stablohm 610
3.Chemical Composition of Ni30Cr20
| C | P | S | Mn | Si | Cr | Ni | Al | Fe | Other |
| Max | |||||||||
| 0.08 | 0.02 | 0.015 | 0.60 | 0.75~1.60 | 18.0~21.0 | 34.0~37.0 | Max 0.50 | Bal. | - |
4.Typical Mechanical properties of Nicr3020
| Yield strength | Tensile Strength | Elongation |
| Mpa | Mpa | % |
| 370 | 750 | 35 |
5.Temperature Factors Of Electrical Resistivity
| 20ºC | 100ºC | 200ºC | 300ºC | 400ºC | 500ºC | 600ºC |
| 1 | 1.011 | 1.024 | 1.038 | 1.052 | 1.064 | 1.069 |
| 700ºC | 800ºC | 900ºC | 1000ºC | 1100ºC | 1200ºC | 1300ºC |
| 1.073 | 1.078 | 1.088 | 1.095 | 1.109 | - | - |
6.All shape of Nichrome
Wire, ribbon( flat wire ), strip, bar, plate, tube
7.size of Ni30Cr20
| Wire | 0.018mm-10mm |
| Ribbon | 0.05*0.2mm-2.0*6.0mm |
| Strip | 0.5*5.0mm-5.0*250mm |
| Bar | 10-100mm |
