Waterproof PP 96 Cores Fiber Optic Splitter Box 16 Ports For Wall Mount
Price:
NEGOTIABLE
MOQ:
200PCS
Delivery Time:
1WEEK
Brand:
YINGDA
Product Description
IP68 PP 96Cores FTTH Fiber Optic Splice Box With SC/UPC Connecors, Fiber Access Terminal Box
FTTH drop cable type fiber optic splice & splitter closure features with ruggedness, which is ested under harsh conditions and stand up to even the most severe conditions of moisture, vibration and extreme temperatures. Humanized design helps user get better experience and safer operating environment.
Features
Dis-mountable adaptor panel
Support midspan termination
Easy operation and installation
Rotatable and dis-mountable splice tray for easy splicing
Specification
| Model | FDB0216F |
| Adapter | 16pcs of SC |
| Cable ports | 1 uncut port, 2round ports |
| Applicable cable diameter | Uncut port: 10-17.5mm, round ports:8-17.5mm |
| Drop cable ports | 16ports |
| Applicable cable diameter | 2*3mm FTTH drop cable, 2*5mm figure 8 FTTH drop cable |
| Dimension | 385*245*130mm |
| Material | Modified polymer plastic |
| Sealing structure | Mechanical sealing |
| Color | Black |
| Maximum splicing capacity | 96fibers (4trays, 24fibers/ tray) |
| Applicable spliter | 1pc of 1*16 plc splitter or 2pcs 1*8 plc splitters |
| Sealing | Ip68 |
| Impact test | IK10 |
| Pull test | 100N |
| Midspan entry | Yes |
| Storage (tube/micro cable) | Yes |
| Net weight | 4kg |
| Gross weight | 5kg |
| Packing | 540*410*375mm (4pcs per carton) |
