IP54 8 Port FTTH Fiber Optical Termination Box Mid Span Anti UV Shocking Resistance Gray PC Alloy
Price:
0.18USD-4.29USD
MOQ:
500pc
Delivery Time:
Negotiable
Brand:
YINGDA
Product Description
IP54 8 Port FTTH Fiber Optical Termination Box Anti UV Shocking Resistance Gray PC Alloy
This product integrates the function of splicing and splitting, suitable for the straight through or branch connection, and terminal connection in optical system, protection connection for cables and distribution pigtails. The cables can be spliced with indoor cables by splitting to meet the requirement of traditional network.
Specification
| Model | FAT-8T-B | ||
| Dimension(mm) W*D*H | 210*125*47 | Material | ABS+PC |
| Max splice | 20 FO | Cable in/out |
4 INLETS 8 OUTLETS |
| No. Of fiber adapter | 8 pcs of SC | No. Of PLC splitter | 2pcs of 1x8 PLC |
| Color | Light grey | Weight | 0.45KG |
Features:
- High impact plastic PC+ABS, standard user interface SC
- Suitable for 1x8 PLC splitter
- Anti-UV, shocking resistance d.
- Wall mount application with scerws
- Unique middle panel≥180°, clear area for splicing and distribution, less cross- connection for cables
- IP-54 protection level for indoor use.
Technical data:
- Fiber bend radius:≥40mm
- Splice tray excess loss:≤0.01dB
- Temperature Range : - 40℃ + 60℃
- Anti lateral pressure : ≥2000N / 10 cm
- Shock resistance:≥20N.m
Key word: 8 port terminal box, fiber access point, fiber terminal box, termination box, ftth box
