400DPI Military EMC Trackball Module Rear Panel Mounted USB 2.0
Military Level EMC Trackball Module 400DPI Resolutions Rear Panel Mounted
DESCRIPTION:
1:50.0mm (2.0’') vandal proof IP65 mechanical trackball module,
2:black harden resin ball with 400DPI resolutions
3:designed to meet MIL-STD-461G and MIL-STD-810F standard, military level,
4:with strong anti-interference ability, and low radiation etc.,
5:USB 2.0 interface, with rear panel mounted solution.
DIMENSIONS: 72.6mm x 72.6mm x 34.5mm
TECHNICAL SPECIFICATION
| ITEM | SPECIFICATION | |
| Mechanical Data | Ball diameter | 50mm/2.0’' |
| Track ball lifespan | > 5 years | |
| Dimension | 50.0 mm diameter for ball, 72.6mm x 72.6mm x 34.5mm | |
| Interface | USB2.0 | |
| Weight | 0.3KGs | |
| Electrical | Power supply | +5V DC +/-5% |
| Protection level | IP65 (static) | |
| EMC Standard | EN 55032:2015, EN 55035:2017 | |
| Power consuming | ≤1.00W(dynamic) | |
| ≤0.2W(static) | ||
| Environmental | Operating temperature | -40ºC~+ 60º C |
| Storage temperature | -45ºC~+ 70ºC | |
| Operating RH | 30～90% | |
| Atmospheric pressure | 60～106Kpa. | |
| Reliable | Certificates | RoHS compliant, CE and FCC certified |
| MTBF | >20000h | |
| MTTR | < 30min | |
| OS | All Windows, Linux | |
| Packing Details | Each unit to a suitable brown inner box, suitable brown inner boxes to a standard export carton. | |
APPLICATIONS
MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
MILITARY: Army, Navy, Air force
MAIN FEATURE
Emulates most popular mice - uses existing mouse driver and mouse software Interfaces for most workstations and computers.
Rate sensitive dynamic resolution provides for accelerated movement of the cursor when the ball is moved fast, while retaining one-pixel positioning accuracy when the ball is moved slowly.
