High Power Flood Light 50W Logistic Airport Stadium Projector Lamp High Mast Led Flood Light
High Power Flood Light 50W Logistic Airport Stadium Projector Lamp High Mast Led Flood Light
Features:
1. Adopting to high power integrated RGB LED, which ensures light is more uniform,light efficiency is higher.
2. Standard DMX512 signal input, internal control and external control.
3. Unique wireless control, control distance up to 50m
4. Built-in 350mA constant current driver design to ensure light for a stable work
5. Using high transmittance tempered glass,transimittance 93%
6. Complying with ROHS,absolutely not contain mercury or other harmful substance
7. Lifespan is over 35000 hours
8. May realize "online address grogramming
Applications:
Widely used in various building walls of light color decoration,stage,meeting rooms,display light, ancient building, cultural plaza etc.
Parameter Performance:
|
Material |
Die-cast aluminum |
|
Input Voltage |
DC24V |
|
Power Efficiency |
≥90% |
|
Beam Angle |
150º 65º |
|
Led chip |
Epistar,Bridgelux,Epileds |
|
Power(Single LED) |
1W |
|
LED Qty. |
9/18/30/48 |
|
Control |
DMX512/1990 /RF |
|
Signal Line |
With IP68 waterproof gold-plated terminal connector |
|
RF Frequency |
335MHz |
|
RF Distance |
30-50m |
|
IP Code |
IP66 |
|
Operatinal condition |
Temperature:-30℃~50℃ |
|
Lifespan |
>35000hrs |
Technical Data:
|
Model |
Product Dimension(mm) |
Power (W) |
LED luminous flux |
Control mode |
N.W |
|
LY-FL1010RGB-D/R |
L120xW95xH130 |
10 |
Red: 100-140lm |
DMX512/RF |
0.51KG |
|
LY-FL1020RGB-D/R |
L205xW157xH250 |
25 |
Red: 220-300lm |
DMX512/RF |
1.8KG |
|
LY-FL1030RGB-D/R |
L205xW157xH250 |
35 |
Red: 380-480lm |
DMX512/RF |
2.03KG |
|
LY-FL1050RGB-D/R |
L250xW180xH310 |
55 |
Red: 620-780lm |
DMX512/RF |
2.91KG |
Warning
- Please handle the product with care when open the package.
- Do Not Open the Light Engine
- Do Not Soak the Floodlight into Water
- Do Not Light up the System Without Grounding
- Do Not Use Dimmer
- If the new LED down light is found damaged, please keep the original package and contact us.
- In order to ensure the product work properly, please use the power supply within indicating voltage range.
- Whatever the case, lamps can not be covered by heat resistant gasket or similar materials.
- 1-10V dimming need to be customized.
