Ip66 Waterproof 30Watt Led Flood Lights Outdoor With Aluminum Material
Ip66 Waterproof 30Watt Led Flood Lights Outdoor For Road park basketball field
Features:
| Power: | 30w |
| Material: | Aluminum Alloy/PC |
| Chip: | Epistar |
| Light efficiency: | 80-90Lm/w |
| Color Temperature: | 2700 -3000K 4000-4500K 5000-6000K |
| CRI: | Ra70 |
| Beam Angle: | 120 degree |
| PF: | >0.95 |
| Working Life: | ≥ 50000 hrs |
| Warranty: | 3 years |
| Dimensions | |
| Finishing Color: | Black |
| Wire connection: | L(Brown);N(Blue);G(Green/Yellow) |
| SHAPE: | Rectangle |
| Package: |
2pcs/carton |
| Work Environment | |
| Input Voltage: | AC100-240V/50-60Hz |
| Operating Temperature: | -40~ + 60°C |
| Application | |
| Application: |
Projector / Floodlight |
| Recommend mounting height: |
3-6m |
1. Adopting high power integrated LED, which ensures light is more uniform,light efficiency is higher.
2. Using high transmittance tempered glass,transimittance93%
3. Complying with ROHS,absolutely not contain mercury or other harmful substance
4. Lifespan of whole tube over 35000 hours
5. LED lamp turn on automatically when the body through the sensor area.
6. Can identify day and night automatically, the ambient-light can be selected to work at night automatically and stop in the daytime.
7. Time-delay can be adjusted vary to the place.
Technical Data:
|
Material |
Die-cast Aluminum |
|
Input Voltage |
AC100-240V 50/60Hz |
|
Power Efficiency |
≥85% |
|
Power factor |
≥0.95 |
|
Beam Angle |
100º 50º |
|
LED Luminous efficiency |
≥90lm/W |
|
Color Temperature |
Warm white WW 2800-3500K |
|
Detection range |
120º |
|
Detection distance |
12m |
|
Time-delay |
Min:5sec Max:6min±2min |
|
Ambient-light |
<3Lux-2000Lux |
|
Installation |
height:2m-4.5m |
Product Descriptions:
|
Model |
Product Dimension(mm) |
Power |
LED Luminous flux |
Average Iilluminance |
Facula Area |
Net Weight |
|
LY-FL1010PW-P |
L115xW85xH106 |
12 |
760-860lm |
1m=289lux |
1M=3.5x3.5M |
0.65KG |
|
LY-FL1020PW-P |
L225xW230xH125 |
25 |
1700-1900lm |
2m=110lux |
2M=3.5x3.5M |
2.13KG |
|
LY-FL1030PW-P |
L225xW230xH125 |
35 |
2550-2850lm |
2m=155lux |
2M=3.5x3.5M |
2.14KG |
|
LY-FL1050PW-P |
L285xW270xH135 |
55 |
4250-4750lm |
4m=80lux |
4M=9x9M |
2.98KG |
Applications:
Suitable for workshop, factory, garden, road and other automatic control occasion.
FAQ:
1. Q: What's the led chip for the modular flood light?
A: Lumileds Luxeon 5050 chips.
2. Q: what's the driver brand?
A: Meanwell or Inventronics driver.
3. Q: what's the delivery time?
A: for sample,5-7 working days; for mass production order,10-12 working days.
4. Q: what's the product warranty?
A: 5 years warranty
5. Q: Can you provide OEM design?
A: Yes,OEM or ODM design is available
