Super Brightness UFO High Bay Light 240w Lumileds Chips Meanwell driver CRI>80
Super Brightness UFO High Bay Light 240w Lumileds Chips Meanwell driver CRI>80
01. UFO High Bay 240W Features
1) UFO design, lighter and nicer. Best for industrial lighting.(such warehouse,stadiums etc.)
2) Brand Lumileds 3030 chip inside. High lumens output>120lm/w for whole lamp.
3) Top class Meanwell driver, high efficency. PF>0.95.
4) Rugged die-casting aluminium alloy body coated with black anti-corrision coating, excellent heat dissaption.
5) High brightness,luminaire 130lm/w, 100w/150w/200w/240w for application.
6) 60 /90 /120 degree beam angle for optional, light weight, easy assembly & installation.
02. Led High Bay Light Advantages
1) LED chips plus Meanwell HBG driver, 5 years warranty.
2) High brightness,luminaire 130lm/w, 100w/150w/200w/240w for application.
3) 60 /90 /120 degree beam angle for optional, light weight, easy assembly & installation.
03. UFO LED High Bay Light Parameter
| Part No. | LY-HB38240-XX (XX for CCT) |
| Power | 240watts |
| Inptut voltage | AC100V～240V 50/60HZ |
| Lumens | 29300lm |
| LED Source | SMD3030 |
| LED QTY | 360pcs |
| LED Driver | / MEAN WELL Brand |
| Beam Angle | 60/90/120degree |
| CRI | ＞80 |
| Color Temperature | 2700-3000K,4000-4500K,5000-5700K |
| Meterial | Magnesium Aluminum + PC cover |
| Lifespan(hrs) | 50,000hrs |
| IP Rating | IP65 Protection |
| Product Size(mm) | Φ400X204 |
| NET Weight(KG) | 5.0KG |
| Warranty | 5 years |
04.200W Led High Bay Light Pictures
05 LED High Bay Aging Test
100% of all lamps will be tested by auto testing line which including different voltage, and keep lighting for 24 hours to test its quality reliability and we will also test its temperature after 24 hours’ lighting. Each lamp should pass all these QC procedures before shipping to customer.
06. LED UFO High Bay Instatllation Guide
07.100W LED High Bay Application
The lamp can be widely used in Warehouse,Industrial workshops,Logistics centers,Exhibition halls,Stadiums,Docks,Golf courses,Airport,Highway toll stations,supermarkets Light engineering.
For More Information, Pls Feel Free To Contact Us
FAQ
- What about the lead time?
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
