RGB Driver IP65 Outdoor LED Flood Lights 50w Reflector Module Design White Housing
IP65 outdoor lighting led rgb 50w reflector, module design RGB led flood light 30w
1. Control mode:RF/IR/DMX512. Standard DMX512 input interface and a built-mode controller , can be realized in whole or segmented light change control, especially, it can achieve water and complicated effects.
2. Adoption LEYOND exclusive Lens with light transmittance up to 98%.
3. Perfect Light Distribution Solution:Adoption of integrated shell optic lens, enhance the brightness and illumination uniformity.
4. There are 25°,,60°, 90° beam angle options for the Lens.
5. Master or Slave function, if set master, it can stead of the external controller.
6. Reliable constant current driver designed to ensure high-power LED lights for a stable job.
7. Superior ability to adapt to the environment, protection grade IP65, can adapt to a variety of indoor and outdoor temperature and humidity environment. The lamp base is aluminum alloy, solid ,anti-aging, anti-variant, long service life.
8. More than 16777 thousand kinds of colors can be realized output, with good light efficiency, beautiful color and so on.
Specifications:
|
Model
|
LY-ST23050RGB
|
|
Product Name
|
50w RGB led flood light
|
|
Modules number
|
1pcs
|
|
Power
|
50w
|
|
Input Voltage
|
AC90~305V 50/60Hz
|
|
Chip Brand
|
Prolight 5050
|
|
Led Qty
|
28pcs
|
|
Driver Brand
|
RGB driver
|
|
Warranty
|
5 Years
|
| Power Factor |
0.95/230V
|
|
Power Efficiency
|
>90
|
|
Input Current
|
0.23A/220V AC
|
|
Beam Angle
|
24° 60° 90°
|
|
Product Size
|
320×128x96mm
|
|
Gross weight
|
2.6KG
|
|
IP Rating
|
IP65
|
|
Meterial
|
Die-cast aluminum
|
|
Certification
|
CE&ROHS
|
Photometric Specifications:
|
Emitting Color
|
λd / CCT
|
Typical Lumens
|
Forward Voltage
|
Forward Current
|
|
RED
|
620-630nm
|
1800lm
|
13-17V
|
1300mA(MAX)
|
|
GREEN |
520-530nm
|
2200lm
|
21-25V
|
1300mA(MAX)
|
|
BLUE
|
460-465nm
|
560lm
|
21-25V
|
1300mA(MAX)
|
|
White
|
R+G+B |
2000lm
|
13-25V
|
1300mA(MAX)
|
