China Indoor p2.5 Full Color LED Display with Compact Cabinet Size and High Pixel Density for Detailed Indoor Visual Presentations for sale

Indoor p2.5 Full Color LED Display with Compact Cabinet Size and High Pixel Density for Detailed Indoor Visual Presentations

Price Negotiable

MOQ: 10 sqm

Delivery Time: 6 working days

Brand: SCX

Product Description

High Definition Indoor Full Color LED Display Front Installation

Products Description

Item		Indoor P1.875	Indoor P2	Indoor P2.5
Module	Panel Dimension	240(W)*240(H)mm	256(W)*128(H)mm	320(W)*160(H)mm
	Pixel pitch	1.875mm	2mm	2.5mm
	Pixel Density	284444 dot/m2	250000 dot/m2	160000 dot/m2
	Pixel configuration	1R1G1B	1R1G1B	1R1G1B
	Specification	SMD1515	SMD1515	SMD2121
	Pixel resolution	128 dot * 128 dot	128 dot * 64 dot	128 dot * 64 dot
	Max power consumption	33W	20W	30W
	Panel weight	0.3KG	0.25KG	0.39KG

Item		Indoor P1.875	Indoor P2	Indoor P2.5
Cabinet	Cabinet size	480mm480mm85mm	512mm512mm85mm	500mm500mm85mm
	Cabinet Resolution	256 dot * 256 dot	256 dot * 256 dot	256 dot * 256 dt
	Quantity of panel	4pcs	8pcs	8pcs
	Hub connecting	HUB-HD26P	HUB75-E	HUB75-E
	Cabinet Material	Diecsting aluminum cabinet	Diecsting aluminum cabinet	Diecsting aluminum cabinet / Iron cabinet
	Maintenance Method	Front/Back service	Front/Back service	Front/Back service
	Best viewing angle	170/ 120	170/ 120	140/ 120
	Screen power supply	AC110V/220V - 5V60A	AC220V(-250V) - 5V40A	AC110V/220V - 5V60A
	Max power capicity	900 W/m2	800W/m2	780 W/m2
	Average power	450 W/m2	400W/m2	390 W/m2

Item		Indoor P1.875	Indoor P2	Indoor P2.5
Technical Signal Index	Driving IC	ICN 2163 / 2065	ICN 2163 / 2065	ICN 2037 / 2153
	Scan Rate	1/32S	1/32S	1/32S
	Refresh frepuency	1920-3840 HZ/S	1920-3840 HZ/S	1920-3300 HZ/S
	Display color	409640964096	409640964096	409640964096
	Brightness	600-800 cd/m2	800- 1000 cd/m2	800- 1000 cd/m2
	Life span	100000Hours	100000Hours	100000Hours
	Control distance	< 100M	< 100M	< 100M
	Best viewing distance	1-30M	2-20M	2-30M
	Operating temperature	- 10C°~60C°	- 10C°~45C°	- 10C°~45C°
	Operating Humidity	10-70 %	10-90 %	10-90 %
	IP protective index	IP43	IP43	IP43

case

>> Most in Kinglight and 3840 refresh rate, if need to change detail,

and More Pixel Pitch and techinal details, feel free to contact us <<

,the shipment time is 3-8 working days after delivery.As for detailed cost, it depends on your final order.
