Rental Soft Module P5 Advertising LED Screen HD Full Color Indoor Video Wall
Front Service P5 Big Indoor Led Video Wall Screen Full Color High Brightness
Product Description
1) Good illumination, no mosaic.
2) Can play different formats of image files, Flash, TV, video and video signals from other devices.
3) Different video frequencies can be changed freely at the same time, and the image can be enlarged or reduced.
4) High brightness and adjustable to meet various needs of customers.
5) Adopting real pixels instead of virtual pixels for better viewing effect.
6) Support module and cabinet front-end service, each module is equipped with 6 magnets for installation.
what is the advantages of our P5 led display moudle?
1. High quality:
Our basic guarantee: aging time is more than 24 hours. The failure point rate is less than 0.0001. MTBF is more than 10000 hours, which guarantees high brightness and long life.
2. Perfect display effect:
High brightness, clear LED display effect, easy-to-use control system, let you easily become an enviable LED display expert.
3. Attractive factory price:
We are a professional manufacturer with our own factory and production line. Without middlemen and trading companies, our price is more competitive and quality is more reliable.
4. Automotive equipment:
Carrier has several automatic production line equipments, with Taiwan automatic sealing machine and Taiwan Changyu processing machine, producing LEDs that meet the needs of high quality standard LED displays.
Specifications :
| outdoor SMD P5 | |||||
| Resolution/mm | 5 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 40000/m² | ||||
| Module resolution | 64x32 | ||||
| Module size/mm | 320x160mm | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
