P4 Indoor Aluminum Panel HD Waterproof SMD LED Screen Billboard 1R1G1B Rental
P4 Interiror Aluminum HD waterproof SMD LED Screen billboard 1R1G1B For rental
1. CNC+ die-casting process cabinet
The CNC+ die-casting process greatly improves the flatness of the LED screen surface (accuracy can reach 0.05mm), ensuring seamless and accurate installation of the full screen.
2. Ultra-thin
The thickness is 60mm, saving installation space and packaging size, ensuring fast movement and installation.
3. Light weight
The full screen weighs only 10KG, one person can easily hang it, and two people only need 30 minutes to complete the installation of a 12 square meter LED screen, saving time and labor costs.
4. Easy and fast installation
We have adopted a plug-and-play design for this series, and the input and output operations of the power and signal connectors are very convenient and fast; the signal connection can be horizontal and vertical, meeting rental applications in any situation.
Specifications :
| Outdoor P4 LED advertising Display Screen | ||
| Information | Pixel Pitch | 4mm |
| Pixel Density | 62500 Pixels/m2 | |
| Pixel Configuration | 1R1G1B | |
| LED Wavelength | Red: 615 nm - 635 nm | |
| Green: 520 nm - 535 nm | ||
| Blue: 465 nm - 475 nm | ||
| LED Module | Module Size(mm) | 256(Width) × 128 (Height) |
| Module Resolution | 64(Width) × 32 (Height) | |
| Cabinet | Cabinet Size(mm) | 512 (Width) ×512(Height) |
| Cabinet Resolution | 128 (Width) × 128 (Height) | |
| Total QYT Module Per Cabinet | 4 (Width) ×4(Height) | |
| Cabinet Weight | 30kg/m2 | |
| Cabinet Material | Die-casting Aluminum LED Display | |
| Power | Input Voltage | 100-240V AC, 50/60Hz |
| Max Power Consumption | 1200 Watt/m2 | |
| Avg. Power Consumption | 720 Watt/m2 | |
| Brightness | ≥1800cd/m2 | |
| Brightness Uniformity | Luminance Discrepancy < 5% | |
| Best Viewing Angle | Horizontal:140°,Vertical:70° | |
| Viewing Distance | 5 - 15 meters | |
| Ambint Conditions | Temperature Range | Working:-20deg. to +60deg |
| Operating Humidity | 10%90%RH | |
| Ingression Protection Grade | IP40 | |
| Processing | Scanning Mode | 1/8 scanning |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 | |
| Controller | Linsn or Nova | |
Competitive advantages:
1. P4 SMD outdoor full-color LED display screen has uniform brightness and color;
2. P4 full-color LED screen uses all-black LED chips;
3. Indoor full-color LED video screen has a contrast ratio of up to 1000:1, reflecting the true color of the content;
4. Adopts Sum driver IC, high refresh rate, high grayscale level;
5. Horizontal and vertical 140-degree ultra-large viewing angle;
6. P4 LED display screen has high resolution, suitable for indoor rental activities with high requirements for presentation quality, and its cost is lower than that of large indoor LED display screens;
