Outdoor Building Full Color P10 Waterproof LED Display Screen 10mm SMD3535
Price:
290$-552$
MOQ:
5 pieces
Delivery Time:
7-15 working days after receive your payment
Brand:
SCXK
Product Description
Outdoor Full Color P10 Waterproof HD High Brightness Advertising LED Display Screen Panels
Product Specifications
| Attribute | Value |
|---|---|
| Pixels | 10mm |
| Pixel Density | 10000 |
| Led Type | SMD3535 |
| Cabinet Size | 960*960*85mm |
| Working Voltage | DC5V-20~55 |
| Dot Density | 10000dots/sqm |
| Driving Mode | 1/4scaning |
| Module Size | 320*160 |
| Module Resolution | 32*16 |
Product Overview
Outdoor Full Color P10 Waterproof Billboard High Pixels Advertising LED Display Screen Panels deliver exceptional visual performance for outdoor advertising applications.
Key Features
- High intensity with adjustable brightness to suit various environmental conditions
- Excellent uniformity with superior light consistency
- Crisp, detailed display of pictures and characters with true-to-life colors
- Wide viewing angles: 160° horizontal and 140° vertical with no picture distortion
- Individual LED lamp repair capability for lower maintenance costs
Product Advantages
- Price Advantage: Competitive market pricing with superior quality
- Performance Advantage: Excellent uniformity, high consistency, wide viewing angles
- Quality Advantage: Strict quality control from materials to finished product
- Service Advantage: Comprehensive support and reliable cooperation
Applications
Ideal for various outdoor advertising and information display applications including:
- Sports venues and stadiums
- Commercial advertising boards
- Financial institutions and stock exchanges
- Transportation hubs (stations, ports)
- Public spaces and marketplaces
- Educational institutions and government departments
Technical Specifications
| Resolution/mm | 10 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 10000/m² |
| Module resolution | 32*16 |
| Module size/mm | 320*160 |
| View distance | 9-400m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >8000cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/4) |
| Frame rate | 60Hz |
| Refresh frequency | >3500Hz |
| Control mode | Computer synchronous |
Installation
Production Process
- Incoming Inspection
- SMD
- Plug-in
- Wave Soldering
- After Welding
- Testing
- Semi Finished Aging
- Module Assembly
- Gluing
- Finished Aging
- Detection Finishing Warehousing
Packaging Options
- Carton
- Ply-wooden case
- Flight case (customizable)
