Shopping Center LED Billboard P6.67 Outdoor Rental / Fixed Installation LED Screen
P6.67 outdoor led display/great advertising effect/led display board
Introduction
We are specilized in LED Display, which widely in industries of advertisement, pub, airport, station, harbor, gym, banks, school, factory, post office, department store, hospital, revenue office, customer, supervising centre, etc. All the products are exported to America, Russia, Great Britain, France, Austrilia, Greece, Italy, Japan, South Korea, Taiwan, Kazakhstan, etc.
Advantage
1. We have the advantage of producing a full range of LED displays
2: Supply from indoor to outdoor P10, P8, P6, P4, P3, P3.91, P4.81, P2, P2.5, P1.976 have sufficient inventory, while having high quality, so you can buy at ease, with peace of mind!
3. We have 24/7 online customer help customers, and give customers product performance introduction, as well as product advantage analysis; according to customer demand, we will customize products for customers.
According to the customer's needs, we will customize the product for the customer, as well as product advantage analysis; according to the customer's actual situation and the use of the situation, for the customer assessment
Evaluation, choose the most reasonable program
4: At the same time, we can provide customers with professional led display operation and maintenance training.
System Display Troubleshooting
| outdoor SMD P6.67 | |||
| Resolution/mm | 6.67 | ||
| Pixel configuration | 1R1G1B | ||
| Pixel density/pixels/m² | 22478/m² | ||
| Module resolution | 48x24 | ||
| Module size/mm | 320x160mm | ||
| View distance | 14-300m | ||
| Single point brightness adjust | Can be added | ||
| Single point color adjust | Can be added | ||
| White balance brightness | >7500cd/㎡ | ||
| Color temperature | 6500K-9500K | ||
| Horizontal view angle | 120(degrees) | ||
| Vertical view angle | 60(degrees) | ||
| Signal Process bit | 10 or 16bit | ||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||
| Driving mode | Constant driving current | ||
| Scanning mode | 1/4SCANNING | ||
| Frame rate | 60Hz | ||
| Refresh frequency | >3000Hz | ||
| Control mode | Computer synchronous | ||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||
| 255 steps. No grey loss | |||
| Out of control point | <1/10000 | ||
| Working hours | ≥72hours | ||
| Mean Time Between Failure | >5000hours | ||
| Life time | 100000hours | ||
| Life-all-white(brightness halving) | 50000hours | ||
| Environment temperature range | Operating temperature range: -20-45℃ | ||
| Self-check technology | LED spot self-check, communications check, power check, | ||
| temperature monitor(need customization) | |||
| Remote monitoring | Remote supervision and control, record potential fault, | ||
| send out warning signs to the operators.(need customization) | |||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||
| Luminous point width between centres | Deviation<3% | ||
| Brightness uniformity | <10% | ||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||
| Power supply request | AC85-264V(50Hz-60Hz) | ||
| Contrast | (1000:1) | ||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||
| Humidity(working) | working:10-95% | ||
| Humidity(storing) | storing:10-95% | ||
FAQ
1.Q:Are you a factory or trading company?
A:We are a factory,located in Dalang,Longhua District .
2.Q:What kind of payment terms you accept?
A:We accept T/T,Western Union,MoneyGram etc.
3.Q:What's packaging?
A:1.Flight case packaging
2.Wooden case packaging
3.36pcs in one case packaging
4.Customized packaging
4.Q:Does you have CE/ROHS certificates?
A:Yes, we offer the CE & ROHS certificates .
5.Q:What's the shipping method,shipping time?
A:Our products could be shipped by Sea, by Air, and by Express.
by sea:20-40days; by air:5-10days ;by express:3-6days
