Metal Outdoor Colorful Text Waterproof LED Display Sign Roadside Billboards
P25 Outdoor Color Text Waterproof Led Display Picture Sign Road Side Billboard
Introduction
1. P25 outdoor full-color LED display module: Using the new enhanced resolution technology, each P25 module has high brightness, uniform color, and good consistency under direct sunlight.
2. Carefully selected LED chips: To ensure clear and realistic images and good consistency, all RGB LED chips for outdoor full-color screens are of the same level, with the same brightness (±10%) and wavelength (±2.5nm).
3. Advanced protection with imported glue: To ensure the matte background of the LED display, completely absorb the LED refraction light, eliminate shadows and ghosting, the surface of the LED module is polished with imported glue. The polishing thickness of each module does not exceed 1mm, and the color is consistent and uniform.
4. Specially designed mask: The main function of the mask is to protect the LED light from external influences. The mask material is made in the United States, dustproof, waterproof, UV-proof, and beautiful.
Features
1. Adopt DIP technology to make the screen display effect excellent.
2. The cabinet is more solid and corrosion-resistant.
3. Through the synchronous adjustment of screen color and brightness, the screen presents delicate and realistic color performance;
4. High contrast and high refresh rate make the LE display screen present images without delay and smear;
5. Compatible with a variety of signal source inputs, such as AV, S-Video, DVI, VGA, YPbPr, HDMI, SDI, DP, etc.;
6. The professional packaging protection of the aviation box plays a good role in protecting the screen control equipment;
7. The unique waterproof cabinet design meets the IP65 protection standard and can be directly installed outdoors
Specifications
| outdoor DIP P25 | |||||
| Resolution/mm | 25 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 1600/m² | ||||
| Module resolution | 8x8 | ||||
| Module size/mm | 200x200MM | ||||
| View distance | 14-300m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | >7500cd/㎡ | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/4 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Trade Info
1).Trade terms: FOB,CIF,EXW
2).Payment terms: T/T ,Western Union, Paypal, Escrow, Moneygram
3) Payment condition: T/T ,30% deposit before production, 70% balance before delivery
4).Production lead time less 20 sqm: 8-15days, more than 50 sqm:30days. Sample can be deliveried within 3days
5).Shipping: by sea,by air and by express delivery
6).Shipping port: Shenzhen, Mainland China
