Arc RGB Advertising LED Screen P4.81 Outdoor Waterproof HD IP65 Die-Casting Aluminum Case
Curved RGB Advertising LED Screen P4.81 Outdoor HD IP65 Aluminum Cabinet
Short descriptions:
1. High brightness - 5500cd/sqm, and the brightness is adjustable.
2. We have rich experience and can recommend suitable products for you.
3. We have our own freight forwarder, and the freight is relatively low.
4. Outdoor waterproof coefficient is up to 65.
5. We provide a variety of packages for you to choose from.
Specifications :
| Outdoor P4.81 LED Display Screen | |||||
| Resolution/mm | 4.81 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 43222/square meter | ||||
| Module resolution | 52x52 | ||||
| Module size/mm | 250x250 | ||||
| View distance | 5-50m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 5500cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/13 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | >3000Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Questions which are constantly asked:
1.How to make an order?
Just contact us through Skype/Whatsapp/Wechat/Email/Mob,and we will have special engineer to talk with you.
2.What kinds of payment you can accept?
T/T,Western Union.
3.What about shipping?
We have air,sea and if possible,also the land.You can according to the specific circumstances to choose the transparent way.
4.How can i trust you?
We are a manufacture of this kind of product,we have relevent certificates can provide you if necessary.
