Full Color Outdoor Waterproof LED Advertising Screen P3 1200 Nits Brightness IP65 Customized
Outdoor Full Color LED Display P3 Hot Sale 1200nits Brightness IP65
About us:
SHENZHEN SCX ELECTRONICS CO., Ltd. is a professional and integrated manufactory of R&D different
kinds of LED display products since 2001. We started from LEDs encapsulation, more than 10 years experience
in LED industry. As a high-tech enterprise engaged in producing LED advertising screen, traffic sign, mobile screen,
rental screen, front service screen, LED curtain/Grid display, Apple style LED advertising sign, LED outdoor single color,
dual color and full color modules, some creative products such as curved and column display etc.
Specifications:
| SMD P1.667 | |||||
| Resolution/mm | 3 | ||||
| Pixel configuration | 1R1G1B | ||||
| Pixel density/pixels/m² | 111111/square meter | ||||
| Module resolution | 64x64mm | ||||
| Module size/mm | 192x192mm | ||||
| View distance | 3-30m | ||||
| Single point brightness adjust | Can be added | ||||
| Single point color adjust | Can be added | ||||
| White balance brightness | 1200cd/square meter | ||||
| Color temperature | 6500K-9500K | ||||
| Horizontal view angle | 120(degrees) | ||||
| Vertical view angle | 60(degrees) | ||||
| Signal Process bit | 10 or 16bit | ||||
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 | ||||
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km | ||||
| Driving mode | Constant driving current | ||||
| Scanning mode | 1/16 SCANNING | ||||
| Frame rate | 60Hz | ||||
| Refresh frequency | 1920Hz | ||||
| Control mode | Computer synchronous | ||||
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted | ||||
| 255 steps. No grey loss | |||||
| Out of control point | <1/10000 | ||||
| Working hours | ≥72hours | ||||
| Mean Time Between Failure | >5000hours | ||||
| Life time | 100000hours | ||||
| Life-all-white(brightness halving) | 50000hours | ||||
| Environment temperature range | Operating temperature range: -20-45℃ | ||||
| Self-check technology | LED spot self-check, communications check, power check, | ||||
| temperature monitor(need customization) | |||||
| Remote monitoring | Remote supervision and control, record potential fault, | ||||
| send out warning signs to the operators.(need customization) | |||||
| Software environment | WindowsNT,Windows1999,WindowsXP | ||||
| Luminous point width between centres | Deviation<3% | ||||
| Brightness uniformity | <10% | ||||
| Color uniformity(chromaticity coordinate) | ±0.003 | ||||
| Power supply request | AC85-264V(50Hz-60Hz) | ||||
| Contrast | (1000:1) | ||||
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration | ||||
| Humidity(working) | working:10-95% | ||||
| Humidity(storing) | storing:10-95% | ||||
Payment item:
1. Payment terms: 30% of TT in advance and 70% before delivery.
2. Delivery time (lead time): 12-15 working days after receiving the deposit.
3. Warranty period Warranty period: free maintenance within 2 years after delivery.
4. Free Training: You can send engineers with electronic knowledge to our factory for training. We will provide free training on how to operate, maintain and repair the LED display.
