Indoor P5 rental screen 640x640mm digital display aluminum screen led sign board video LED Screen wall
Customized easy installation P5 rental advertising indoor concert stage LED display
Specification
| Module Specification: | |
| Pixel Pitch | 5mm |
| Module Size | 320 x 160 x 16mm |
| LED Encapsulation | SMD2121, 3IN1 |
| Module Power Consumption | ≤19W |
| Cabinet Specification: | |
| Cabinet Size | 640mm x 640mm x 75mm |
| Cabinet Resolution | 128dots x 128dots =16,384dots |
| Pixel Density | 40,000 dots/sqm |
| Cabinet Material | Die-cast Aluminum |
| Cabinet Weight | 14Kg |
| Brightness | 1400 cd/sqm |
| Optimal Viewing Distance | ≥6m |
| Driving Method | 1/16 scan, constant current |
| Max. Power Consumption | 500 W/sqm |
| Ave. Power Consumption | 300 W/sqm |
| Input Voltage | 110~220VAC±10% |
| Life span | ≥100,000 hours( 50% brightness) |
| Payment terms: |
35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
| Packing: |
-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
| Shipping: |
LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
| After-Sales-Service: |
-Lifetime with professional engineer support for free. has quality problem |
Features
1. LED Chip: Supplied by Nichia of Japan & Cree of USA & Epistar of Taiwan or other high strictly
selected LED chip, assure high definition show effect.
2. Wide viewing angle 120/160°, perfect and impressive viewing effect.
3. High quality IC selection: MBI5024/5035/5036/5039/5042/5124/5153, JXI5020, TLC59283 ,
ICN2053BP/2083S or other types you require.
4. Famous power supply selection: Meanwell, E-energy, Greatwall etc., CE, UL certified.
5. Famous control system for optional: Synchronous: Nova, LINSN, Mooncell etc.;
Aynchronous: Tianyi, Xixun or Betters etc.. They are stable, wide application, easy to operate,
good refresh rate and grey scale, powerful functions to support your need.
6. Skillful and strict assembly workmanship, can assure you high quality guaranteed products.
7. All our products support 3 years warranty or more according to your requirements.
8. Immediate, patient and considerated service is our principle.
9. All products are CE, RoHS, FCC, TUV certified.
Our Service
A1:We are a Professional OEM/ODM manufacturer which has specialized in led display industry for 10 years.
A2:LED modules,led screen,led display serie product.
A3: We focus on every detail,Our factory has gained ISO9001, ISO14001, CE, RoHS ,FCC,CCC authentication.
A4:Any quantity is acceptable for your order. And the price is negotiable for large quantity.
A5: Generally, it will take 10 to 25 days after receiving your deposit payment. The specific delivery time depends on the items and the quantity of your order.
A6: 1-3year warranty. Structure design, installation problem, program the screen, how to use the screen…?don’t worry, we have professional after-sale team to solve your any questions after you placed an order. And your exclusive sales engineer will also help you get over any problems.
