Rental Curved Smd HD Indoor Led Display Board, P3.9mm Full Color LED Signage
Rental Curved SMD HD Full Color LED Display P3.9mm Indoor Slim LED Video Screen
Features
P2.9/P3.9/P4.8 Indoor Event Audiovisual Equipment LED Video Wall adopts multiple quick locks and positioning pins, and the flatness and seamlessness are greatly improved, with a precise seamlessness and flatness of 0.01mm. 1. Stage LED Screen: Easy to hang and install, the background video panel is assembled quickly, suitable for stage layout. 2. Conference Room LED Screen: Installed in conference rooms and board rooms as a meeting or stage background. 3. Stadium LED Screen: Installed in stadiums to broadcast live sports events, as a video wall panel 4. Conference Room and Auditorium LED Screen: Installed with portable profile aluminum structure, as a mobile LED screen. 5. Banquet LED Screen: Installed in banquet halls for music videos or event video panel settings. 6. Airport LED Screen: Installed at airports for festival advertising or special video displays.
Specification
Indoor P3.91 high resolution curve LED video wall/LED screen panel/hd LED display screen for TV studio stram video live show
| Item | Technical Specifications | ||||
| Pixel Pitch | 2.97mm | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
| LED Configuration | SMD1010 (3-IN-1) | SMD1010 (3-IN-1) | SMD1010 (3-IN-1) | SMD1010 ( 3-IN-1) | SMD2121(3-IN-1) |
| Pixel Density | 112896pixels/sqm | 65746pixels/sqm | 43264pixels/sqm | 28224pixels/sqm | 25600pixels/sqm |
| Module Size | 250*250mm | 250*250mm | 250*250mm | 250*250mm | 250*250mm |
| Cabinet Szie | 500mm*500mm/500mm*1000mm | ||||
| Cabinet Resolution | 168*168pixels | 128*128pixels | 104*104pixels | 84*84pixels | 80*80pixels |
| Cabinet Material | Die-casting Aluminum cabinet with curved design LED Display Screen | ||||
| Cabinet Weight | 7Kg curved LED Display panel cabinet | ||||
| Brightness | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm | 2000cd/sqm |
| Color Temperature | 3500K-9500K | 3500K-9500K | 3500K-9500K | 3500K-9500K | 3500K-9500K |
| Viewing Angle | H:160°/V:160° | ||||
| Ave Power Consumption | 230W/sqm | 230W/sqm | 230W/sqm | 230W/sqm | 230W/sqm |
| Max Power Consumption | 800W/sqm | 800W/sqm | 800W/sqm | 800W/sqm | 800W/sqm |
| Drive Mode | 1/28scan | 1/16scan | 1/13scan | 1/7scan | 1/10scan |
| Best Viewing Distance | ≥2.97m | ≥3.91m | ≥4.81m | ≥5.95m | ≥6.25m |
| Input Voltage | AC220V/50HZ or AC110V/60HZ(±10%) | ||||
| Output Voltage | 5V 40A | ||||
| Refresh Rate | ≥3840Hz | ||||
| Frame Rate | 50/60Hz/sec | ||||
| Protection Level | IP43 | ||||
| Life Span | 100,000hours | ||||
| Malfunction dot rate | <0.0001 | ||||
| Storage Temp/Humidty | —40~+60°C/10-80%RH | ||||
| Operating Temp/Humidty | —25~+50°C/10-90%RH | ||||
| Input Signal | RF,TV.RGB,S-VIDEO,PAL,DVI,HDMI,VGA,SDI,AVI,RGBHV,CVBS,etc | ||||
| Pc Operating System | Microsoft Windows 7.8.10.98.2000.XP and Vista | ||||
Product Details
| Payment terms: |
35% deposit before production, 65% balance before shipping -T/T: -Paypal -Western Union -Escrow |
| Packing: |
-Standard Export Carton with fully Polyfoam or Pearl Wool -Flight case; -Anti-shaking wooden case |
| Shipping: |
LED module: 3 to 5 working days upon receiving deposit payment LED display: 5 to 8 working days upon receiving deposit payment |
| After-Sales-Service: |
-Lifetime with professional engineer support for free. has quality problem |
Our Service
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Customized design is available,OEM & ODM are welcomed.
4)Exclusive and unique solution can be provided to our customer by our well-trained
and professional engineers and staffs.
5)Special discount and protection of sales area provided to our distributor.
6)Warmly welcome your visit in our company if available.
7)Warranty: 24 months, a little investment for longer warranty time
FAQ
1. Can we make any size of indoor led screen?
Nope , according the led module size and cabient size, such as p3.9 mm indoor led screen,
the smallest unit size is: 500x500mm.
2,What's best size of indoor led screen?
The best aspect ratio of LED display are W16:H9 or W4:H3, recommand order 4x3=12pcs
for the demo ph3.9 mm indoor led screen,
3,How to install indoor led screen?
We will provide drawing of steel structure or hanging truss,then you can install indoor led screen,
very easy.
4,How to order indoor led screen?
Please tell me indoor or outdoor do you need,size of led display,where will be application
of indoor led screen
5,How to shipment?
Normally, ph3.9 mm indoor led screen will be shipped by air or by sea , because the value is
high than other product too much.
