P6 Outdoor Full Color Mobile LED Display Truck Screen IP65 Waterproof
| Attribute | Value |
|---|---|
| Pixel | 6mm |
| Module size | 192*192mm |
| LED chip | Episatr |
| Pixel Configuration | 3 in 1 |
| Warranty | 5 years |
| Viewing Angle(degree) | ≤140° |
| Protection Level | IP65 |
High Brightness, Better Quality for mobile truck LED display
Installing at outdoor places requires displays with high brightness output. The P6 LED Screen Display features high brightness and high definition, ensuring excellent picture quality - making it perfect for stages, banks, highways, promotions, stations, stadiums, and other outdoor locations.
High Refresh Rate for truck LED display
The P6 LED Screen Display uses dynamic scanning mode technology, offering higher brightness and a refresh rate of 1920Hz for superior picture, video, and text quality.
| Lamp size | 3535 |
| Resolution/mm | 6 |
| Pixel configuration | RGB 3 in 1 |
| Pixel density/pixels/sqm | 27778/sqm |
| Module resolution | 32x32 |
| Module size/mm | 192*192MM |
| View distance | ≥5m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >8000cd/sqm |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 14 bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:5km |
| Driving mode | Constant driving current |
| Scanning mode | constant driving static |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ Storing temperature range: -30-65℃ |
| Maximum power:/sqm | <750W |
| Average power:/sqm | <300W |
| Self-check technology | LED spot self-check, communications check, power check, temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT, Windows1999, WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working: 10-95% |
| Humidity(storing) | storing: 10-95% |
Wooden case or flight case package are available. Shipping by sea, air or DHL, multiple shipping options available.
Continuous Quality
With over 10 years of LED display production experience, we regularly update our equipment. Our standardized modular production ensures consistent product quality.
Competitive Price
Our large-scale production capacity and professional technology allow us to maintain efficient modular production while reducing costs to benefit customers.
Fast Delivery
We honor our delivery commitments and use emergency inventory procedures when necessary to maintain uninterrupted supply.
Perfect Service
Pre-sales: We carefully consider your requirements and recommend suitable products. After-sales: We track product usage to continuously improve our offerings.
Our team is committed to providing full support for all your needs!
