Full Color P2 P2.6 SMD2121 40W 1000cd/m2 Stage Led Screens led screen concert stage led screen
Full color stage led screens P2 P2.6 P3 P4 led panel displays interior
Stage Led Screens Application
1) Full color LED display: Equally or compactly make the red, green, blue color in one dot, equally distribute at the panel, and so make the whole display
2). usually apply for physical sports, advertisement, bank, stock exchange, station, port, marketplace, telecommunication, department, school, monitor, restaurant, entertainment, etc.
Stage Led Screens Technical specification
| Item | Parameter | |||
| Module specifications | Mode | p2.604 | p3.91 | p3.91 |
| Module size | 250*250 | 250*250 | 250*250 | |
| Module pixel | 96*96 | 64*64 | 64*64 | |
| scan | 1/32 | 1/16 | 1/16 | |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | |
| LEDs | SMD1515 | SMD2121 | SMD2121 | |
| Max power consumption (W/piece) | 40W | 40W | 40W | |
| Mask | have | have | have | |
| Main Specifications | Cabinet size | 500*500 | 500*500 | 500*1000 |
| Cabinet pixel | 192*192 | 128*128 | 128*256 | |
| Density (dot/m2) | 147456 | 65536 | 65536 | |
| Brightness(cd/m2) | 700-1000 | 700-1000 | 700-1000 | |
| Max power consumption (W/piece) | 160W | 160W | 320W | |
| Avg power consumption (W/piece) | 50W | 50W | 10W | |
| Cabinet weight(KG) | 6KG | 6KG | 11KG | |
| Cabinet material | Die-cast magnesium aluminum box | |||
| IP grade | IP45 | IP45 | IP45 | |
| Gray level | 16 bit | 16 bit | 16 bit | |
| Fresh rate | 3840HZ | 3840HZ | 3840HZ | |
| Best viewing distance | 2.6M | 4M | 4M | |
| Power(V) | AC110-220V | |||
| Working temperature | -20℃-50℃ | |||
Stage Led Screens Projects
Why choose us
Continues Quality
With more than 10 years experience in led display producing,equipments are updated regularly.What’s
more,unique standardized and module production ensure our products continuous quality.
Competitive Price
With large scale production capacity and professional production technology,our company have built
effective modular production.We always stick to promote the technical innovation and reduce cost to
benefit customers.
Fast Delivery
Once we promise the delivery date,we will try our best to fulfill it.Special procedures such as emergency
inventory will be used to maintain your uninterrupted supply of the products.
Perfect Service
Pre-sales:Your purchasing requirements will be highly valued and we’ll recommend suitable products to
you.
After-sales:We will track the products usage and then constantly perfect our products.
