Automatic Climatic Test Walk In Chambers With Air Cooled Type Condenser And Intelligent Touch Screen
Obtained CE certification, temperature and humidity test box desktop is an economical and space-saving machine, suitable for a variety of test requirements.
Simulate the different climatic conditions, test product heat resistance, cold resistance, resistance to drying and moisture resistance, etc., by testing the product under different climatic conditions to see if its performance can meet the expected requirements.
Humidity Control
In the small environment room to control the humidity in the industry is a technical breakthrough. We have a wealth of humidity control expertise, intelligent design can be carefully integrated into the standard room.
The wet bulb humidity sensor is the "main measurement method" of accuracy. It is also economical, easy to maintain and reliable because it does not risk the failure due to excessive saturation.
The product's direct water supply connection is standard and has the option of filtering and circulating water tanks.
The humidity subsystem is designed for reliability, convenience and performance.
The external steam generator allows the expansion range and is easy to maintain.
Features
Touch screen programmer / controller with Ethernet
The Watlow F4T has a touch screen and Ethernet port standard
Save 120 configuration files, up to 1200 steps (slope, soak, jump, auto start, end)
An event relay for external device control, plus a sample power interlock relay to achieve safety
Grande exclusive options include: Web controllers for full remote access; Chamber Connect software for basic data logging and monitoring. USB and RS-232 ports are also available.
High performance and quiet operation (65 dBa)
Space-saving space designed for flat mounting to the wall
Stainless steel appearance
All around the door frame is broken
On the left there is a 50mm (2 ") to 100mm (4") cable port with a flexible silicone plug
Three overheating protection, plus overcooling protection
Easy to disassemble the service panel, the left side of the electrical channel
Removable eight feet power cord plug
Standards
GB10485-89 GB4208-93 GB/T4942 and
Corresponding IEC ISO & ASTM standards
Technical parameters
| Temperature range | -80°C,-73°C,-60°C, -40°C, -20°C, 0°C~+150°C, +180°C | |||||
| Humidity range | 20%~98%RH | |||||
| Temp.&Humi fluctuation | ±0.2°C, ±0.5%RH | |||||
| Temp.&Humi.uniformity | ±1.5°C,±2.5% RH when RH is ≤ 75%,±4% RH when RH is > 75% (tested with the empty chamber, 30 minutes after stabilization) | |||||
| Temp.&humi. Resolution | 0.01°C,0.1%RH | |||||
| Inner chamber material | SUS#304 stainless steel plate | |||||
| Exterior chamber material | Stainless steel plate+ powder coated | |||||
| Insulation | PU & Fiberglass wool | |||||
| Wind circulation | Sirocco fan | |||||
| Heating system | SUS#304 stainless steel high-speed heater | |||||
| Humidifying | Surface evaporating system | |||||
| Cooling | Imported compressor,Tecumseh compressor,finned type evaporator,air-cooling condenser | |||||
| Dehumidifying | ADP critical dewpoint cooling/dehumidifying method | |||||
| Controller | Digital electronic indicators+S.S.R.With PID automatic calculation capability | |||||
| Power supply | 3 phase 380V 60/50Hz | |||||
After-sales service
Serve you 8 days a week
Take an active role to ensure that our equipment proposed will not only meet the specifications but also will be made as per the budget
Provide timely delivery
