Sus 304 Stainless Steel Temperature Humidity Chamber , Environmental Test Equipment
Sus 304 Stainless Steel Temperature Humidity Chamber , Environmental Test Equipment
Environment temperture and humidity chamber applicable to environmental adaptability and reliability test in such industrial units as electronics, electrical appliance, battery, plastics, food, paper product, vehicle, metal, chemistry, building material, research institution, inspection and quarantine bureau, university etc.
| Benchtop Climatic Chamber | ||
| Secifications ( at +20ºC room temp. Or+25ºC water temp with empty load) | ||
| Model | KMH-36L | |
| 36L chamber volume | ||
| Temp. range | -50 ºC~+150ºC | |
| Interior sizel | W(mm) | 300 |
| H(mm) | 400 | |
| D(mm) | 300 | |
| Exterior size | W(mm) | 460 |
| H(mm) | 780 | |
| D(mm) | 1020 | |
| Power(KW) | 4.5 | |
| Weight(KG) | 100 | |
| Temp. constancy | ±0.5ºC | |
| Temp. uniformity | ±2.0ºC | |
| Heat up time | -50ºC~+150ºC, within 70 min | |
| Pull down time | +20ºC~-50ºC , within 60 min | |
| Humidity Range | 20~98%R.H | |
| Humidity constancy | ±2.5%R.H | |
| Standard accessories | Sight window*1, cable port(portΦ50mm)*1, shelves*2, chamber lamp*1, power cable *2m | |
| Safety device (standard) | No fuse breaker, over pressureover heat and over current protection for compressor, | |
| Over temp. protect, over load protect of blower, dry heat protection | ||
| Control System | Balanced Temperature & Humidity Control System | |
| Refrigeration system | Air Cooled (Water Cooled Type is option) | |
| Hermetic compressor,Single stage refrigeration system | ||
| CFC-Free refrigerant(HFC-507/HFC-23) | ||
| Controller | Panel:7-inch LCD Touch panel, Chinese or English display selectable | |
| Operation model :Program or fix point running | ||
| Memory capacity :120programs,1200steps, | ||
| All repeat 999 cycles, part repeat 99 cycles | ||
| Interior material | Stainless Steel Plate(SUS 304) | |
| Exterior material | Baked Painting Steel Or Stainless steel(SUS304) | |
| Insulation material | Rigid polyurethane Foam and Glass Fiber Wool | |
| Ambient Temp. | +5ºC~+35ºC | |
| Wiring method | AC220,50Hz ,1phase 2 wires +Ground Wires | |
| Note: 1. We reserve the right to change specifications without prior notice 2. Customized sizes and configurations available |
||
(1) accurate temperature heating and cooling control
features temperature heating 3℃/min and cooling performance at 1℃/min with no load for our standard model, and can handle temperature cycle tests at 3℃/min cooling down and heating up rate respectively with load for customized model.
(2) highly temperature uniformity distribution
komeg offers highest 0.5 ℃ temperature uniformity distribution, this allows minimizes variations in test results over multiple specimens.
(3) wide selection control range for temperature and humidity
features a wider cont rol range of temperature and humidity, including stable control at 95℃/98%rh.
(4) network solution available
standard communication support is available with rs-485 or rs-232c interface.
An ethernet (lan) port is also available as an option, for simple connection of a computer, tablet computer, or other terminal. Monitoring of chamber’s running conditions, modification of test conditions, starting or stopping operation, and other interaction with the chamber can be performed via a web browser.
GB/Bb T2423.2-89 high temperature test method
GB2423.1-89 test A: low temperature test method 6
GJB150.4-1986 test at low temperature
IEC60068-2-1 low temperature test method
IEC60068-2-38 temperature cycle
IEC60068-2-78 constant humidity temperature
MIL - STD - 202G - 103B humidity test
IEC60068-2-30 humidity temperature cycle
GB/T2423.3 constant humidity heat test method
We use pp film wrapping the test chamber to protect the test chamber from moisture or being scratched first, then use strong plywood case for easyload and transport, and to keep the chambers from potential crash or impact.
